Pressure Gauge 2-1/2 Dial Size MNPT MPN:LFC-220-200-G
The pressure gauge from Flex-a-Seal is designed for use in measuring both positive and negative pressure across various industries including manufacturing, scientific research, laboratories and commercial applications. Its MNPT fitting allows easy installation while its durable construction ensures long lasting use with an accuracy of 0.5% full scale. With a large 2-1/2 dial size, it provides quick and precise pressure readings from 0-30 psig making it suitable for low or high vacuum measurements. This pressure gauge's ability to work in either portrait or landscape orientation makes it perfect for tight spaces while its easy-to-read black on white face display offers clarity even under poor lighting conditions. Whether you are working on a small project or a large scale operation, this pressure gauge provides reliable and accurate pressure measurements making it an essential tool for anyone requiring precision in their work.
Technical Specifications
- Item Pressure Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 2 1/2 in
- Basic Gauge Case Material Plastic
- Basic Gauge Wetted Parts Brass / Bronze
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Center Back
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 200
- Gauge Accuracy +/-3-2-3%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled Yes
- Gauge Primary Range Smallest Graduation 2
- Gauge Case Material ABS Plastic
- Gauge Primary Range Numbered Graduations 20
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Bronze
- Gauge Sensor Material Bronze
- Gauge Lens Material Acrylic
- Gauge Filled With Glycerin
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Gauge Special Options Heavy Duty
- Required Gauge Adapter 1 yr
- Characteristics With Brass Internals
- For Use With Media Compatible with Bronze
- Calibration Certificate Included No
- Series LFC-220
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Span
- Condensed Mfg Number: LFC220200G
- MPN: LFC-220-200-G
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on January 25, 2024 1:50pm UTC Category: Pressure and Vacuum Measuring
