Vacuum Gauge 2-1/2 Dial Size MNPT MPN:LFC-220-30VAC-G
Unibit's premium vacuum gauge is a versatile solution for professionals seeking to monitor vacuum pressure levels in various applications, featuring a dial size of 2-1/2 inches and MNPT connection. Made with high-quality materials, this vacuum gauge delivers reliable and accurate readings while offering easy-to-read numerals and pointer indicators for maximum convenience. The large-size face provides easy readouts in both inches and millimeters while also allowing the user to switch between English and metric measurements based on their preference. Additionally, it comes with a protective dust cap that protects the gauge from dirt, debris or moisture. With its compact design, this vacuum gauge is ideal for use in test instruments where space is limited. Upgrade your monitoring capabilities with Unibit's vacuum gauge - the perfect solution for precise control over your vacuum applications.
Technical Specifications
- Item Vacuum Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 2 1/2 in
- Basic Gauge Case Material Plastic
- Basic Gauge Wetted Parts Brass / Bronze
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Center Back
- Gauge Primary Range Units in Hg
- Gauge Primary Range Values -30 to 0
- Gauge Accuracy +/-3-2-3%
- Pressure and Vacuum Gauge Type Vacuum Gauge
- Gauge Panel Mountable No
- Liquid Filled Yes
- Gauge Primary Range Smallest Graduation 0.5
- Gauge Case Material ABS Plastic
- Gauge Primary Range Numbered Graduations 5
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Bronze
- Gauge Sensor Material Bronze
- Gauge Lens Material Acrylic
- Gauge Filled With Glycerin
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Gauge Special Options Heavy Duty
- Required Gauge Adapter 1 yr
- Characteristics With Brass Internals
- For Use With Media Compatible with Bronze
- Calibration Certificate Included No
- Series LFC-220
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Span
- Condensed Mfg Number: LFC22030VACG
- MPN: LFC-220-30VAC-G
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112406
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Vacuum gauges
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
