4 Bolt Flng Brg Radial 1 9/16in Bore MPN:SF-25
A heavy-duty vertical sheet rack manufactured from powder coated steel with dimensions measuring 32.5 inches height and 30 inches depth providing ample storage space to accommodate large size sheets such as 4ft x 8ft plywood or metal. The durable design allows for stacking, enabling efficient utilization of warehouse floors space reducing congestion during busy production days improving work efficiency. Its versatile nature makes it a popular choice across multiple industries, including automotive, construction or manufacturing sites for easy storage, retrieval & organization of large sized sheets eliminating manual handling thereby enhancing productivity and saving time while keeping valuable stock safe & secure avoiding damage or injury to workers.
Technical Specifications
- Item 4-Bolt Flange Bearing
- Mounted Bearing Item 4-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 1 9/16 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Cast Iron
- Bearing Insert Material 52100 Chrome Steel
- Bolt Hole Center-to-Center 4 in
- Series SF
- Bolt Size 1/2 in
- Overall Height 5 1/8 in
- Overall Width 2 1/64 in
- Overall Length 5 1/8 in
- Bearing Lubrication Sealmaster GoldPlex-HP or NLGI #2 Equivalent
- Dynamic Load Capacity 7,340 lb
- Static Load Capacity 4,467 lb
- Temp. Range -20 Degrees to 220 Degrees F
- Finish Black Oxide
- Dimension A 5 1/8 in
- Dimension B 4 in
- Dimension C 9/16 in
- Dimension D 1 1/2 in
- Dimension E 2 1/64 in
- Dimension F 17/32 in
- Dimension G 33/64 in
- Dimension H 2 1/64 in
- Dimension J 4 5/64 in
- Dimension L 2 1/16 in
- Dimension M 1 3/16 in
Manufacturer Details
- Manufacturer: Sealmaster
- Condensed Mfg Number: SF25
- MPN: SF-25
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: ZZ
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Flanged bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
