4 Bolt Flng Brg Taper Roll 1 1/4in Bore MPN:RFP 104
SKU
226-CXO-44A461
4 Bolt Flng Brg Taper Roll 1 1/4in Bore
The 4 bolt flange bearing, taper roller conical style with a bore of 1.25 inches is commonly used in power transmission systems such as gearboxes or differentials where high radial and axial loads must be supported, transmitted or absorbed evenly across various shaft sizes. This type of bearing reduces friction while permitting angular misalignment thereby prolonging equipment lifetimes by minimizing wear or damage from load induced vibrations typical of heavy machinery in automotive, mining, agricultural, construction and other industries.
✓ Buy Sealmaster item #RFP 104 and get Free Shipping from our large selection of Hardware Accessories and show your support for Veteran-Owned Businesses.
Technical Specifications
- Item 4-Bolt Flange Bearing
- Mounted Bearing Item 4-Bolt Flange Bearing
- Bearing Insert Type Tapered Roller
- Bore Dia. 1 1/4 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Cast Iron
- Bearing Insert Material 52100 Chrome Steel
- Bolt Hole Center-to-Center 4 1/8 in
- Series RFP
- Bolt Size 3/8 in
- Overall Height 5 in
- Overall Width 2 3/4 in
- Overall Length 5 in
- Bearing Lubrication Sealmaster GoldPlex-HP or NLGI #2 Equivalent
- Dynamic Load Capacity 2,975 lb
- Static Load Capacity 1,390 lb
- Temp. Range -20 Degrees to 220 Degrees F
- Finish Black Oxide
- Dimension A 2 3/4 in
- Dimension B 5 in
- Dimension BC 4 1/8 in
- Dimension C 1 3/4 in
- Dimension D 3 3/8 in
- Dimension E 7/8 in
- Dimension F 1 19/64 in
- Dimension G 2 1/4 in
- Dimension H 3/64 in
- Dimension J 4 1/8 in
- Dimension L 2 1/4 in
- Dimension N 7/8 in
- Dimension P 3 3/8 in
Manufacturer Details
- Manufacturer: Sealmaster
- Condensed Mfg Number: RFP104
- MPN: RFP 104
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: ZZ
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Flanged bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on October 20, 2023 3:49pm UTC
Category: Bearings
