4 Bolt Flng Brg Taper Roll 3 7/16in Bore MPN:RFB 307
SKU
226-CXO-44A459
4 Bolt Flng Brg Taper Roll 3 7/16in Bore
The 4 bolt flanged boring bar tapering 3-7/16 inches bore provides an exceptional choice for machinery, aerospace or transportation industries requiring precision and strength with its sturdy construction while offering versatility through its 16 overall length. It simplifies the process of boring, drilling or machining processes delivering reliability in various settings while providing cost-effective and efficiency at a higher speed than other taper roll reamers in the market. Suitable for professionals or DIY enthusiasts seeking to improve their accuracy and finish quality on round parts such as pipes or cylindrical surfaces, the flange design allows proper alignment with the workpiece while preventing it from spinning during operation.
✓ Buy Sealmaster item #RFB 307 and get Free Shipping from our large selection of Hardware Accessories and show your support for Veteran-Owned Businesses.
Technical Specifications
- Item 4-Bolt Flange Bearing
- Mounted Bearing Item 4-Bolt Flange Bearing
- Bearing Insert Type Tapered Roller
- Bore Dia. 3 7/16 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Cast Iron
- Bearing Insert Material 52100 Chrome Steel
- Bolt Hole Center-to-Center 7 in
- Series RFB
- Bolt Size 3/4 in
- Overall Height 9 1/4 in
- Overall Width 5 1/4 in
- Overall Length 9 1/4 in
- Bearing Lubrication Sealmaster GoldPlex-HP or NLGI #2 Equivalent
- Dynamic Load Capacity 15,320 lb
- Static Load Capacity 4,710 lb
- Temp. Range -20 Degrees to 220 Degrees F
- Finish Black Oxide
- Dimension A 5 1/4 in
- Dimension B 9 1/4 in
- Dimension BC 10 61/64 in
- Dimension C 4 1/2 in
- Dimension D 7 in
- Dimension E 1/4 in
- Dimension F 3/4 in
- Dimension G 1 7/8 in
- Dimension H 1 7/8 in
- Dimension J 6 in
- Dimension L 5 1/2 in
- Dimension M 8 in
- Dimension N 2 1/2 in
Manufacturer Details
- Manufacturer: Sealmaster
- Condensed Mfg Number: RFB307
- MPN: RFB 307
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: ZZ
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Flanged bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 3, 2024 10:10pm UTC
Category: Bearings
