4 Bolt Flng Brg Radial Ball 3 1/4in Bore MPN:MSF-52
4 Bolt Flng Brg Radial Ball 3 1/4in Bore
The indexable boring bar offers a precision solution for multiple machining operations with its high speed steel body featuring cutting inserts thus ensuring high accuracy and efficiency in every use. With a minimum bore diameter of 7.9mm, an 8mm shank dia and 92 degree chamfer thus delivering superior strength and rigidity to maintain constant cutting pressure during operation, making it ideal for industries such as automotive, aerospace or construction thus providing superior performance in all applications.
Get Sealmaster item #MSF-52 from our selection of Hardware Accessories while supporting Veterans 🎖.
Technical Specifications
- Item 4-Bolt Flange Bearing
- Mounted Bearing Item 4-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 3 1/4 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Cast Iron
- Bearing Insert Material 52100 Chrome Steel
- Bolt Hole Center-to-Center 6 3/4 in
- Series MSF
- Bolt Size 3/4 in
- Overall Height 8 7/16 in
- Overall Width 3 17/32 in
- Overall Length 8 7/16 in
- Bearing Lubrication Sealmaster GoldPlex-HP or NLGI #2 Equivalent
- Dynamic Load Capacity 18,681 lb
- Static Load Capacity 14,496 lb
- Temp. Range -20 Degrees to 220 Degrees F
- Finish Black Oxide
- Dimension A 8 7/16 in
- Dimension B 6 3/4 in
- Dimension C 1 in
- Dimension D 2 3/4 in
- Dimension E 3 17/32 in
- Dimension F 25/32 in
- Dimension G 25/32 in
- Dimension H 3 17/32 in
- Dimension J 7 1/4 in
- Dimension L 4 5/32 in
- Dimension M 2 1/32 in
Manufacturer Details
- Manufacturer: Sealmaster
- Condensed Mfg Number: MSF52
- MPN: MSF-52
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: ZZ
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Flanged bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on June 10, 2023 12:46am UTC
Category: Bearings
