IEC Magnetic Contactor, 1NC, 480V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1K0901T7
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient switching device designed for various industrial applications. With its 3-pole, non-reversing configuration and 480V AC coil, it provides precise control over electrical circuits. The unit features a 1NC auxiliary contact, screw clamp terminals, and a compact design suitable for DIN rail or plate mounting. Ideal for use in control panels, machine tools, and other industrial equipment, this contactor offers improved safety and reduced downtime. Its durable construction and high-performance capabilities make it an excellent choice for applications requiring precise electrical switching and control.
Top product features:
- It has a 3-pole design.
- It features a normally closed auxiliary contact.
- It is compatible with DIN rail or plate mounting.
Top product applications:
- Industrial Automation
- Power Distribution Systems
- Control Panel Design
Schneider Electric’s IEC Magnetic Contactor is a 3-pole, non-reversing electric switching device rated for operation within specified parameters. It features a 480V AC coil and screw clamp terminals, with one normally closed auxiliary contact (1NC). The unit is part of the TeSys K series and is compatible with DIN rail or plate mounting
- IP20 is the specified ingress protection rating.
Key features:
- - Item: IEC Magnetic Contactor
- Series: TeLis K
- Reversing Capability: Non-Reversing
- - Poles: 3
- Auxiliary contacts: 1NC
- Includes auxiliary contacts: Yes
- Auxiliary contact form: 1NC
- - Coil voltage: 480V AC
- Maximum voltage rating: 480V AC
- Frequency: 50/60 Hz
- - Terminal connection: Screw Clamp
- Mounting style: DIN Rail, Plate
- - IP rating: IP20
- - Full Load Amps: rated for use at indicated current levels under specified conditions
- - Electrical operating durability: tested for a number of operational cycles under standard test conditions
- - Mechanical operating durability: 10,000,000 cycles
- - Insulation resistance: measured according to applicable standards
- - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, GB/T 14048.4, JIS C8201-4-1, UL 60947-4-1
- - Dimensions: Depth 2.24 in
- Height 2.28 in
- Width 1.77 in
- - Embedded surge suppressor: No
Additional Information
- Country of Origin: FR
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.44
- Package Width: 1.89
- Package Height: 2.60
- Package Weight: 0.40
