Miniature Circuit Breaker, MULTI9 Series, 15A, 2 Pole, Not Rated, 5kA at 500V DC, C Curve MPN:MGN61530
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0450466
Miniature Circuit Breaker, MULTI9 Series, 15A, 2 Pole, Not Rated, 5kA at 500V DC, C Curve
The MULTI9 Series 15A 2 Pole Miniature Circuit Breaker from Schneider is a reliable and efficient solution for distribution applications. This IEC Supplementary Protector features a thermal magnetic trip type and meets UL Type UL 1077 standards. With a maximum air rating of 5kA at 500V DC and a C curve type, it provides effective protection against overcurrent and short circuits. Suitable for use in various industries, this circuit breaker is ideal for applications requiring high reliability and minimal downtime. Its compact design and ease of installation make it a valuable addition to any distribution system.
Top product features:
- Protects against electrical overloads with a thermal magnetic trip mechanism
- Detects and responds to changes in electrical current with a C Curve trip characteristic
- Mounts securely on DIN rail for easy installation and organization in distribution applications
Top product applications:
- Distribution
- DC Power Systems
- Low Voltage Systems
IEC Supplementary Protector, Amps 15 A, AC Voltage Rating Not Rated, Max. AIR Rating 5kA at 500V DC, Series C60H-DC, Curve Type C, DC Voltage Rating 500V DC, Number of Poles 2, Phase 1, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style DIN Rail, Meets UL Type UL 1077, Terminal Connection Lug, Trip Type Thermal Magnetic, Application Distribution, Min. Wire Size 18 AWG, Max. Wire Size 4 AWG, Length 3.19 in, Width 1.42 in, Depth 2.87 in, Residual Current Type A
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.30
- Package Width: 3.80
- Package Height: 1.60
- Package Weight: 0.55
Product info last updated on January 31, 2026 1:48am UTC
Category: Circuit Protection
