H8150 Open Power Relay 6 Pin 240VAC DPST-NO MPN:199AX-10
The Schneider H8150 Open Power Relay is an exceptional choice for power control applications in demanding industrial environments. This heavy-duty relay features high voltage coil ratings of 240V AC, ensuring efficient and reliable operation even under high-power demands. With AC contact rating of 40A @ 300V and DC contact rating of 40A @ 28V, this relay can handle the most challenging electrical loads with ease. Its robust construction allows for operation in extreme temperatures ranging from -40 to 80 degrees Celsius. With six pins and a dual pole double throw (DPDT) configuration, this relay offers versatile connections for controlling electrical loads in machines, robots, vehicles, and more. The Schneider H8150 Open Power Relay delivers unparalleled reliability and performance, making it an essential component for demanding industrial applications.
Top product features:
- High-power coil voltage of 240V AC
- Dual pole double throw (DPDT) configuration for versatile connections
- Robust construction allowing operation in extreme temperatures (-40 to 80 degrees Celsius)
Top product applications:
- Industrial automation systems and machinery
- Commercial equipment such as elevators, escalators, and HVAC systems
- Electric vehicles and renewable energy solutions like solar panels or wind turbines
Technical Specifications
- Item - Relay Open Power Relay
- Coil Volts 240V AC
- AC Contact Rating - Relay 40A @ 300V
- DC Contact Rating - Relay 40A @ 28V
- Number of Pins - Relay 6
- Contact Form - Relay DPST-NO
- Mounting - Relay Surface
- Power Consumption - Relay 10.0 VA
- Contact Material Silver Alloy
- Electrical Connection - Power Relay Screw
- Body Height - Relay 2.25 in
- Body Width - Relay 2.5 in
- Body Depth - Relay 2.43 in
- Overall Height - Relay 2.25 in
- HP @ 120V 2
- HP @ 240V 2
- Hz - Electrical 50/60 Hz
- Features Riveted Construction
- Standards cULus/cURus/CSA/CE
Manufacturer Details
- Manufacturer: Schneider
- Condensed Mfg Number: 199AX10
- MPN: 199AX-10
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Power Relays
- GDS Family Name: Relays
- GDS Segment Name: Electrical
- UNSPSC: 39121514
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Switches and controls and relays and accessories
- UNSPSC Commodity ID: 14
- UNSPSC Commodity Name: Power relays
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on May 7, 2025 5:30am UTC Category: Relays
