H2713 IEC Control Relay 5NO 24VDC 10A MPN:CAD50BD
Free Shipping
In Stock
Schneider's H2713 IEC Control Relay is an essential device for anyone seeking reliable control and switching solutions for their electrical systems. With its powerful performance capabilities, this relay is ideal for a wide range of applications in various industries such as lighting control, machine automation, and more. Its 5NO (Normally Open) configuration ensures smooth operation and the ability to switch up to five loads at once. The 24VDC coil voltage and 10A contact rating make it compatible with a variety of low voltage systems, while its 120/240/480/600V AC contact rating ensures that it can handle high current loads. With 12 pins for versatile connection options and UL certification for added safety, this relay is a top-of-the-line choice for any project requiring precise control and reliability. Upgrade your electrical system with Schneider's H2713 IEC Control Relay today!
Top product features:
- Normally Open (NO) Configuration
- 24VDC Coil Voltage
- 10A Contact Rating
Top product applications:
- Lighting Control Systems
- Motor Speed Control Circuits
- Load Shedding Applications
Technical Specifications
- Item - Relay IEC Style Control Relay
- Coil Volts 24V DC
- AC Contact Rating - Relay 10A @ 120/240/480/600V
- DC Contact Rating - Relay 2.00A @ 125/250/600V
- Number of Pins - Relay 12
- Contact Form - Relay (5) SPST-NO
- Mounting - Relay DIN Rail, Surface
- Power Consumption - Relay 8.0 VA
- Body Height - Relay 2.91 in
- Body Width - Relay 1.77 in
- Body Depth - Relay 4.72 in
- Overall Height - Relay 3.03 in
- Response Time Drop Out: 8 msec, Pick Up: 16 msec
- Contact Material Silver Nickel
- Standards CE, CSA, UL
Manufacturer Details
- Manufacturer: Schneider
- Condensed Mfg Number: CAD50BD
- MPN: CAD50BD
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: ID
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8537109060
- GDS Category Name: IEC and NEMA Style Relays
- GDS Family Name: Relays
- GDS Segment Name: Electrical
- UNSPSC: 39121535
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Switches and controls and relays and accessories
- UNSPSC Commodity ID: 35
- UNSPSC Commodity Name: Control relays
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
