Ovrload Rely 1 to 1.60A 3P Class 10 690V MPN:LRD06
SKU
226-CXG-3EA42
Ovrload Rely 1 to 1.60A 3P Class 10 690V
The light fixture offers powerful illumination, energy efficiency, with an efficient aluminum body design ensuring longevity; suitable for commercial spaces requiring bright lighting such as offices or workshops, garages with high ceilings where traditional lights struggle to provide enough coverage. Typical users may include retailers, wholesalers operating in industrial zones demanding reliable, durable equipment while minimizing operational expenses and seeking energy-efficient alternatives. This model excels in showcasing products prominently within warehouses, factories or other big spaces where visibility is essential for optimal productivity levels.
TeSys™ IEC Contactors and Overload RelaysFor industrial motor control applications, combine a contactor with an overload relay to make a complete motor starter. Rated 600VAC. Saddle clamp terminals. DIN rail• or panel-mount.UL Listed, CSA and CE Certified.Overload RelaysFor 3-phase applications. Bimetallic elements. Class 10 trip characteristics with 1-phase sensitivity. Ambient compensated. Adjustable current range. Lockable, sealable, manual/auto reset, test trip. Mount to underside of contactor.
Technical Specifications
- Item - Relay IEC Style Overload Relay
- Use With - Contactors and Starters Mfr. Series LC1D09 to LC1D32 Contactors
- Overload Relay Current Range 1.00 to 1.60A
- Trip Class - Overload 10
- Number of Poles 3
- Reset Type - Relay Manual
- Body Height - Relay 3.62 in
- Body Width - Relay 1.77 in
- Body Depth - Relay 2.75 in
- Overall Height - Relay 3.62 in
- Sensing Method Bimetallic
- Features Single Phase Sensitivity, Differential
- Standards ATEX D 94/9/CE, CSA, GOST, UL
Manufacturer Details
- Manufacturer: Schneider
- Condensed Mfg Number: LRD06
- MPN: LRD06
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: FR
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8537109090
- GDS Category Name: IEC Overload Relays
- GDS Family Name: Starters and Contactors
- GDS Segment Name: Electrical
- UNSPSC: 39121520
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Switches and controls and relays and accessories
- UNSPSC Commodity ID: 20
- UNSPSC Commodity Name: Overload relays
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on November 17, 2023 12:18pm UTC
Category: Starters and Contactors
