Stndrd Dty Indstrl Fan 42 Blde Dia 2Spd MPN:VKM42-2-O
The O1 oil-hardening flat stock is an exceptional tooling option that offers several advantages for various applications. With its thickness of 3 mm, width of 75 mm and length of 1000 mm, this versatile product provides excellent balance between strength and rigidity while maintaining accuracy during cutting operations. The +0.05 mm tolerance ensures precise dimensions which result in more consistent results with fewer errors or repairs, saving time and cost during manufacturing processes. O1 steel has superior wear resistance capabilities as compared to other high-speed steels making it suitable for applications that require heavy usage such as knife making, machine tool parts, cutlery among others. The oil-hardening process also enhances the steel's ability to retain its sharpness after heat treatment providing a longer lasting cutting edge. Overall, this O1 flat stock delivers premium performance at an affordable price for anyone involved in metalworking projects requiring hardened steel components.
Technical Specifications
- Item Standard-Duty Industrial Fan
- Blade Diameter 42 in
- Wheeled Base Mobile
- Oscillation Non-Oscillating
- Watts 1129/425
- Number of Speeds 2
- Voltage 115V AC
- Phase 1
- Air Flow 7700/11,000 cfm
- Motor HP 1 hp
- RPM 565/379
- Amps 12.3/5.6
- Fan Mounting Location Floor
- Air Velocity @ 10 Ft. 700/450
- Air Velocity @ 20 Ft. 425
- Air Velocity @ 40 Ft. 300
- Assembly Required No
- Sound Level 72 dBA
- Max. Ambient Temp. 104 Degrees F
- Hz 60
- Motor Enclosure Totally Enclosed Air-Over
- Motor Insulation Class B
- Motor Type Permanent Split Capacitor
- Thermal Protection Auto
- Bearing Type Self-Aligning Pillow Block Bearings
- Fan Cord Length 5 ft
- Height 45 3/4 in
- Width 45 1/2 in
- Depth 22 in
- Number of Blades 3
- Blade Material Galvanized Steel
- Shaft Dia. 5/8 in
- Fan Housing Material Polyethylene
- Guard Material Steel
- Wire Guard Finish Gloss White Powder Coated
- Drive Type Belt
- Standards UL
- Environmental Applications Industrial
Manufacturer Details
- Manufacturer: Schaefer
- Condensed Mfg Number: VKM422O
- MPN: VKM42-2-O
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8414596595
- GDS Category Name: Industrial Fans
- GDS Family Name: Cooling Fans and Air Circulators
- GDS Segment Name: HVAC and Refrigeration
- UNSPSC: 40101602
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Air circulation and parts and accessories
- UNSPSC Commodity ID: 02
- UNSPSC Commodity Name: Air circulators
- UNSPSC Family ID: 10
- UNSPSC Family Name: Heating and ventilation and air circulation
- UNSPSC Segment ID: 40
- UNSPSC Segment Name: Distribution and Conditioning Systems and Equipment and Components
Shipping Details
- Not For Sale In: HI AK PR
