Electrical H Box 4-11/16 in 42.0 cu in MPN:257H
SKU
226-CXG-2NYF4
Electrical H Box 4-11/16 in. 42.0 cu in
The Electrical H Box is a weatherproof box constructed using aluminum, providing IP66 & NEMA 3R protection to wiring connections for outdoor installations, ensuring resistance against dust & rain while offering clean, organized mounting of up to 42.0 cu inch of wires. Key features include 4 terminal studs for secure wire connection, quick release cover for easy installation or maintenance, UL/CSA approved design adhering to all relevant electrical safety standards making it an ideal choice for various outdoor applications including lighting, security systems etc., promoting safe & efficient wiring solutions!
Use this box in applications where larger-sized conductors or wiring devices are needed and additional volume is required. The bottom knockouts are not usable with the FS support.
Technical Specifications
- Item Electrical Box
- Box Type Square with Bracket
- Number of Gangs 2
- Bracket Type H Style
- Capacity 42.0 cu in
- Material Galvanized Steel
- Number of 1/2 In. Back Knockouts 5
- Number of 1/2 In. Side Knockouts 12
- Number of 3/4" Back Knockouts 2
- Number of 3/4" Side Knockouts 12
- Nominal Depth 2 1/8 in
- Nominal Length 2 1/8 in
- Nominal Width 4 11/16 in
- Color Silver
- Standards UL
Manufacturer Details
- Manufacturer: Raco
- Condensed Mfg Number: 257H
- MPN: 257H
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 7326908688
- GDS Category Name: Electrical Boxes
- GDS Family Name: Electrical Boxes
- GDS Segment Name: Electrical
- UNSPSC: 39121303
- UNSPSC Class ID: 13
- UNSPSC Commodity Name: Electrical boxes and enclosures and fittings
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Electrical boxes
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
