Female Rod End LH 8 mm Bore M8-1.25 MPN:MGFL8T
Female Rod End LH 8 mm Bore M8-1.25
These extra-length solid carbide drill bits come with a durable finish of AlCrN & TiAlN coating which increases their life span considerably offering users more productivity while cutting multiple materials like stainless steel or titanium alloy up to 9mm diameter holes in just one piece! Suited perfectly for machinists, contractors & engineers drilling applications across industries including manufacturing facilities requiring deep hole drilling capabilities without compromising precision making them reliable choice when it comes time investing into powerful yet efficient machining tools.
This steel spherical rod end is engineered to allow pivoting in the housing to compensate for misalignment in industrial applications. It features a precision-ground, hardened 440C stainless steel ball and 300 Series stainless steel body with bonded PTFE fabric race. Excellent for low- to moderate load applications where lubricating the parts is not desirable.
Technical Specifications
- Item Stainless Steel/PTFE Race Rod End
- Type Female Plain
- Ball 440C Stainless Steel Spherical
- Thread Left Hand
- Thread Size M8 x 1.25
- Inside Dia. 8/8.065mm
- Bearings 440C SS Spherical Ball
- Housing 300 Series Stainless Steel
- Construction Follows SAE Specification J1120
- Dimension A M8 x 1.25
- Dimension AA 8/8.065mm
- Dimension E 22.25 mm
- Dimension G 36 mm
- Dimension H 17 mm
- Dimension J 47.125 mm
- Dimension N 12 mm
- Max. Angular Misalignment 28 Degrees
- Static Radial Load 9,340 N
Manufacturer Details
- Manufacturer: QA1
- Condensed Mfg Number: MGFL8T
- MPN: MGFL8T
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483308055
- GDS Category Name: Spherical Rod Ends
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171508
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 08
- UNSPSC Commodity Name: Rod end bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
