Female Rod End LH 1/4 in Bore 1/4 -28 MPN:GFL4TS
Female Rod End LH 1/4 in Bore 1/4 -28 is an excellent rod end bearing that provides precision alignment for mechanical components used across automotive, machinery, and aerospace industries. Its right-hand thread ensures secure attachment of pistons to rods or control arms and tie rod ends on suspension systems with a 1/4 inch bore diameter. Stainless steel or alloy steel construction guarantees durability even under extreme conditions, while the precise alignment it offers enhances performance safety. With its versatile applications across various engineering fields, this female rod end bearing caters to mechanical engineers, technicians, and machinists who require precise alignment in their power transmission systems for optimal performance and safety.
Technical Specifications
- Item PTFE Race Rod End
- Type Female Studded
- Ball 440C Stainless Steel Spherical
- Thread Left Hand
- Thread Size 1/4"-28
- Stud Length 0.562 in
- Bearings 440C Stainless Steel Spherical Ball
- Housing 300 Series Stainless Steel
- Construction Follows SAE Specification J1120
- Dimension A 1/4"-28
- Dimension B 0.469 in
- Dimension C 0.562 in
- Dimension E 0.75 in
- Dimension G 1.312 in
- Dimension H 0.687 in
- Dimension J 1.687 in
- Max. Angular Misalignment 27 Degrees
- Static Radial Load 2,165 lb
Manufacturer Details
- Manufacturer: QA1
- Condensed Mfg Number: GFL4TS
- MPN: GFL4TS
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483308055
- GDS Category Name: Spherical Rod Ends
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171508
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 08
- UNSPSC Commodity Name: Rod end bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
