Male Rod End LH 7/16 in Bore 7/16 -20 MPN:CML7S
With a size of Hex Head, 2.75, Dimensions, 7/16 inches long, material Type SS (Stainless Steel), thread count Plain, Pitch 14 and comes packaged as a kit with ten pieces (PK), this fastener delivers impressive strength to withstand heavy-duty applications. Offering superior corrosion resistance that outlasts other non-stainless steel alternatives, the HxHdCpScrwSS27571614TENP is ideal for both interior and exterior fastening needs where durability is key. Often used in industrial or construction environments, this bolt is a must-have tool among professional technicians or casual DIYers when tackling demanding tasks requiring utmost strength, resilience and precision. Suitable within numerous industries such as automotive, aerospace, or general manufacturing, the HxHdCpScrwSS27571614TENP fastener adds a reliable solution to any toolkit for quick fastening and ease of use.
Technical Specifications
- Item Rod End
- Type Male Studded
- Ball 52100 Steel Spherical
- Thread Left Hand
- Thread Size 7/16"-20
- Stud Length 1.062 in
- Bearings 52100 Steel Spherical Ball
- Housing Carbon Steel
- Construction Follows SAE Specification J1120
- Dimension A 7/16"-20
- Dimension B 0.688 in
- Dimension C 1.062 in
- Dimension E 1.125 in
- Dimension G 2.125 in
- Dimension H 1.375 in
- Dimension J 2.688 in
- Max. Angular Misalignment 21 Degrees
- Static Radial Load 7,897 lb
Manufacturer Details
- Manufacturer: QA1
- Condensed Mfg Number: CML7S
- MPN: CML7S
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483308055
- GDS Category Name: Spherical Rod Ends
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171508
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 08
- UNSPSC Commodity Name: Rod end bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
