Female Rod End RH 7/16 in Bore 7/16 -20 MPN:NFR7S
This single outlet adapter features one NEMA 5-15R female plug with a 125VAC rating for North America applications while providing users the convenience of an additional power point when more are needed. The device comes with a durable, flexible rubber casing that not only ensures the connection remains tight even during transportation but also safeguards against any unintended short-circuit hazards due to accidental contact with conductive surfaces. Its compact size and lightweight design make it easy to install in multiple locations or fit conveniently into toolbags, ideal for both indoor and outdoor uses where temporary power solutions are required at workstations or events; construction sites are typical settings which benefit largely from these adapters alongside several industrial sectors seeking convenient access points around equipment and machinery without compromising safety regulations.
Technical Specifications
- Item Nylon/PTFE Race Rod End
- Type Female Studded
- Ball 52100 Steel Spherical
- Thread Right Hand
- Thread Size 7/16"-20
- Stud Length 1.062 in
- Bearings 52100 Steel Spherical Ball
- Housing Carbon Steel
- Construction Follows SAE Specification J1120
- Dimension A 7/16"-20
- Dimension B 0.688 in
- Dimension C 1.062 in
- Dimension E 1.125 in
- Dimension G 1.812 in
- Dimension H 1.062 in
- Dimension J 2.375 in
- Max. Angular Misalignment 14 Degrees
- Static Radial Load 5,350 lb
Manufacturer Details
- Manufacturer: QA1
- Condensed Mfg Number: NFR7S
- MPN: NFR7S
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483308055
- GDS Category Name: Spherical Rod Ends
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171508
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 08
- UNSPSC Commodity Name: Rod end bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
