Female Rod End RH 7/16 in Bore 7/16 -20 MPN:NFR7
Female Rod End RH 7/16 in Bore 7/16 -20
Socket screws are a widely used fastener type utilized in various assembly applications requiring mechanical attachment of components where high strength and adjustability without the need for tools is necessary. Featuring a hexagonal socket head for maximum torque transfer during tightening, this M6 size flat point self-tapping steel screw variant enables easy starting with metal surfaces when driven into thin materials like sheet metal, wood or plastic. Manufactured from stainless steel alloy offering enhanced corrosion resistance suitable for harsh environments, they come in packs of 50 providing exceptional value to users seeking an economical and reliable option ideal for general industrial, automotive, or repair applications.
This steel spherical rod end is designed to allow pivoting in the housing to compensate for misalignment in industrial applications. It features a precision-ground, chrome-plated hardened 52100 steel spherical ball, 1045 carbon steel body, and nylon/PTFE compound molded race. The self-lubricating design helps make it ideal for low to moderate load applications where parts lubrication is not desirable. Note: Not for automotive or aircraft use.
Technical Specifications
- Item Nylon/PTFE Race Rod End
- Type Female Plain
- Ball 52100 Steel Spherical
- Thread Right Hand
- Thread Size 7/16"-20
- Inside Dia. 0.4375/0.4395 in
- Bearings 52100 Steel Spherical Ball
- Housing Carbon Steel
- Construction Follows SAE Specification J1120
- Dimension A 7/16"-20
- Dimension AA 0.4375/0.4395 in
- Dimension E 1.125 in
- Dimension G 1.812 in
- Dimension H 1.062 in
- Dimension J 2.375 in
- Dimension N 0.562 in
- Max. Angular Misalignment 14 Degrees
- Static Radial Load 5,350 lb
Manufacturer Details
- Manufacturer: QA1
- Condensed Mfg Number: NFR7
- MPN: NFR7
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483308055
- GDS Category Name: Spherical Rod Ends
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171508
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 08
- UNSPSC Commodity Name: Rod end bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
