Linear Rail 13 In L 0.437 W 1.062 In H MPN:VRSD4-013.000
This linear rail with dimensions measuring 13 in length, 0.437 in width, and 1.062 in height is an ideal component for various power transmission systems requiring accurate and stable linear motion across its full stroke range. Its black anodized finish ensures longevity while also resisting wear and tear providing a clean finish that's impervious to contamination or corrosion over time, enhancing its suitability in industrial settings. The steel construction delivers exceptional rigidity while minimizing thermal expansion offering users accurate and consistent performance ideal for precision applications such as assembly machines, CNC tables, or automated production systems requiring linear motion control. It's also readily mountable onto appropriate bearing blocks or rails enabling quick and effortless installation, making it a reliable solution in demanding power transmission applications that demand robustness without compromising on smoothness of movement.
Technical Specifications
- Item Drilled Linear Rail
- Type V-Guide
- Overall Length 13 in
- Overall Width 0.437 in
- Overall Height 1.062 in
- Number of Rail Holes 4
- Mounting Hole from Shaft End 0.5 in
- Mounting Hole Center to Center 4 in
- Mounting Hole Size 0.344 in
- Thread Size 0.312 in or M8
- Screw Type Low Profile Socket Head Cap
- Temp. Range 0 - 248F
- Rail Material Stainless Steel
- Rail Finish Cold Roll
- Raceway 303 Stainless Steel
- For Use With V-Guide Wheels and Bushings
Manufacturer Details
- Manufacturer: Pbc Linear
- Condensed Mfg Number: VRSD4013000
- MPN: VRSD4-013.000
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Linear Guide Rails
- GDS Family Name: Linear Motion
- GDS Segment Name: Power Transmission
- UNSPSC: 23153030
- UNSPSC Class ID: 30
- UNSPSC Commodity Name: Holding and positioning and guiding systems and devices
- UNSPSC Commodity ID: 30
- UNSPSC Commodity Name: Linear motion guides
- UNSPSC Family ID: 15
- UNSPSC Family Name: Industrial process machinery and equipment and supplies
- UNSPSC Segment ID: 23
- UNSPSC Segment Name: Industrial Manufacturing and Processing Machinery and Accessories
Shipping Details
- Not For Sale In: HI AK PR
