Coupler Plug, Steel, 1/2 In. Pipe, 110 cfm MPN:H3G-F
The Parker H3G-F Quick Connect Plug is a reliable and efficient solution for pneumatic applications. This steel-made plug features a trivalent chrome finish and a push/pull locking mechanism, allowing for easy connection and disconnection of hoses or equipment. With a maximum working pressure of 300 psi and a temperature range of -40°F to 250°F, this plug is suitable for a variety of industrial applications, including manufacturing, construction, and oil and gas. Its compact size and durable construction make it an ideal choice for applications where quick connections and disconnections are necessary.
Top product features:
- The product has a push/pull locking mechanism for easy connection and disconnection of hoses or equipment.
- The fitting is constructed of steel with a trivalent chrome finish for durability and corrosion resistance.
- The product is rated for a maximum working pressure of 300 psi at 70°F and a temperature range of -40°F to 250°F.
Top product applications:
- Pneumatic applications such as pneumatic tools and equipment
- Industrial pneumatic systems that require quick and easy hose connections
- Automotive repair shops and garages that use pneumatic tools for brake and tire work
The PARKER - H3G-F is a quick connect hose coupling designed for pneumatic applications. It enables connection and disconnection of hoses or equipment using a push/pull locking mechanism. Constructed of steel with a trivalent chrome finish, it provides a connection intended to be compatible with the specified pneumatic coupling interface and pressure/temperature ratings. The fitting is specified for use with a 3/4 in nominal coupling size and a 1/2 in hose fitting size.
Key Features:
- - Material: Steel with trivalent chrome finish with a trivalent chrome finish.
- - Connection Type: Female NPT thread with a 1/2" -14 thread size.
- - Coupling Component: Plug (male half of the quick-connect system).
- - Body Size: 3/4 in nominal size.
- - Hose Fitting Size: 1/2 in.
- - Maximum Working Pressure: is rated for a maximum working pressure of 300 psi at 70°F.
- - Temperature Range: is rated for operation within the range of -40°F to 250°F.
- - Overall Length: 2.25 inches.
- - Maximum Outside Diameter: 1 3/16 inches.
- - Barbed: No.
- - Interchange Type: is compatible with specified industrial interchange standards (as applicable to the stated connection/interface types).
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.20
- Package Width: 1.20
- Package Height: 1.20
- Package Weight: 0.25
