Elbow 90 SS CPIxF 3/8Inx1/2In MPN:6-8 DBZ-SS
Elbow 90 SS CPIxF 3/8Inx1/2In
Our Elbow 90 SS CPIxF 3/8Inx1/2In is a versatile and durable tube fitting that is perfect for a variety of applications. With its brass construction, it offers superior resistance to corrosion, making it ideal for use in harsh environments. Its pressure rating of 600 PSI ensures reliability under high-pressure situations. Plus, its sleeve insert mechanism provides ease of assembly and disassembly without the need for tools, making it a convenient choice for both installations and repairs. Whether you're working in plumbing or hydraulics, this elbow fitting is an excellent addition to any system where 90-degree connections are needed.
With a compression design that allows for easy assembly this PARKER CPI™ female elbow provides a leaktight seal for high pressure, vibration, and vacuum in gas or liquid applications. Features a single-ferrule design creates a dynamic seal on tube and body, with close tolerance of nut and body dimensions for accurate tube alignment. Fitting won’t twist the tubing during installation so that the mechanical integrity of the tubing is preserved. Has a 4:1 safety factor with respect to the working pressure capabilities of the tubing used. Can be used with 304, 316, or 316L stainless steel tubing. For use in refineries, chemical processing, power generation, and instrument lines.
Technical Specifications
- Item Female Elbow, 90 Degrees
- Tube Fitting Material Stainless Steel
- Fitting Connection Type CPI(TM) x FNPT
- Pipe Size - Pipe Fitting 1/2 in
- Tube Size 3/8 in
- Compression Thread Size 9/16-20
- Hex Size 1 in
- Temp. Range -425 Degrees to 1200 Degrees F
Manufacturer Details
- Manufacturer: Parker
- Condensed Mfg Number: 68DBZSS
- MPN: 6-8 DBZ-SS
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 7307225000
- GDS Category Name: Compression Couplings Adapters Unions and Elbow
- GDS Family Name: Tube Fittings
- GDS Segment Name: Plumbing
- UNSPSC: 40142604
- UNSPSC Class ID: 26
- UNSPSC Commodity Name: Tube fittings
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Tube elbows
- UNSPSC Family ID: 14
- UNSPSC Family Name: Fluid and gas distribution
- UNSPSC Segment ID: 40
- UNSPSC Segment Name: Distribution and Conditioning Systems and Equipment and Components
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 4, 2024 8:48am UTC
Category: Tube Fittings
