H8109 Flange Relay 24VAC 4 Pins 10A @ 240V AC MPN:G2R-1A-T-AC24

Technical Specifications

• Item - Relay Flange Mount Relay
• Coil Volts 24V AC
• AC Contact Rating - Relay 10A @ 240V
• DC Contact Rating - Relay 10A @ 28V
• Number of Pins - Relay 4
• Contact Form - Relay SPST-NO
• Mounting - Relay Top Flange
• Power Consumption - Relay 0.9 VA
• Contact Material Silver Alloy
• Status Indicator No
• Electrical Connection 0.187 in Solder Terminals
• Body Height - Relay 1.16 in
• Body Width - Relay 1.2 in
• Body Depth - Relay 0.46 in
• Overall Height - Relay 1.49 in
• HP @ 120V 1/3 hp
• HP @ 240V 1/2 hp
• Features Creepage Distance of 8.0 mm M in Between Coil and Contact
• Standards CSA Certified, UL Listed

Manufacturer Details

• Manufacturer: Omron
• Condensed Mfg Number: G2R1ATAC24
• MPN: G2R-1A-T-AC24

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: MY
• CA Prop 65 Wht Label: N

Classification Details

• Harmonization Code: 8536490080
• GDS Category Name: Flange Mounted Relays
• GDS Family Name: Relays
• GDS Segment Name: Electrical
• UNSPSC: 39121515
• UNSPSC Class ID: 15
• UNSPSC Commodity Name: Switches and controls and relays and accessories
• UNSPSC Commodity ID: 15
• UNSPSC Commodity Name: General purpose relays
• UNSPSC Family ID: 12
• UNSPSC Family Name: Electrical equipment and components and supplies
• UNSPSC Segment ID: 39
• UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies

Shipping Details

• Not For Sale In: HI AK PR
