H8070 Gen Purpose Relay 5 Pin Square 12VDC MPN:G2R-1-S-DC12(S)
H8070 Gen Purpose Relay 5 Pin Square 12VDC
The H8070 relay is an ideal device for control applications designed with a robust construction capable of enduring rigorous industrial environments where relays require consistent performance under demanding conditions. It operates on a voltage supply ranging between 8.5VDC to 16V providing versatility when used in diverse situations, while its rating spans up to 30A rendering it suitable for handling substantial power demands. Its gold plated pinout connector improves connectivity allowing the relay to maintain superior conductivity and shield against signal losses, making it a dependable pick amongst professional installations requiring flawless operations across varying scenarios within plug-in relay systems.
Slim and space-saving power plug in relay with built-in mechanical flag indicator. Provides high switching power and has manual push to test. Designed with cadmium-free contact material and ia suitable for general-duty applications. Includes standard socket-mount or solder terminals and nameplate.
Technical Specifications
- Item - Relay General Purpose Relay
- Coil Volts 12V DC
- AC Contact Rating - Relay 10A @ 240V
- DC Contact Rating - Relay 10A @ 28V
- Base Type - Plug In Relay Square
- Number of Pins - Relay 5
- Contact Form - Relay SPDT
- Mounting - Relay Plug In
- Socket Code - Relay H
- Power Consumption - Relay 0.5 W
- Contact Material Cadmium Free
- Status Indicator Mechanical Flag
- Push To Test Manual
- Body Height - Relay 1.4 in
- Body Width - Relay 0.51 in
- Body Depth - Relay 1.14 in
- Overall Height - Relay 1.6 in
- HP @ 120V 1/3 hp
- HP @ 240V 1/2 hp
- Standards CSA Certified, UL Listed
Manufacturer Details
- Manufacturer: Omron
- Condensed Mfg Number: G2R1SDC12S
- MPN: G2R-1-S-DC12(S)
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MY
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536410050
- GDS Category Name: Plug-In Relays
- GDS Family Name: Relays
- GDS Segment Name: Electrical
- UNSPSC: 39121514
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Switches and controls and relays and accessories
- UNSPSC Commodity ID: 14
- UNSPSC Commodity Name: Power relays
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
