H8070 Gen Purpose Relay 5 Pin Square 24VAC MPN:G2R-1-S-AC24(S)
H8070 Gen Purpose Relay 5 Pin Square 24VAC
The H8070 general purpose relay is ideal for various applications across diverse industries including consumer electronics, security systems and automotive devices. It offers multiple configurations such as 5VAC/DC or 24VAC operating voltage to ensure compatibility with a range of control circuits. With an excellent low current noise and high isolation performance, the relay is suited for switching AC or DC loads. The SPDT contacts of this component are designed to sustain a 10A load which increases its functionality in demanding applications, making it suitable for use by professionals and DIY enthusiasts alike who need dependable relay solutions.
Slim and space-saving power plug in relay with built-in mechanical flag indicator. Provides high switching power and has manual push to test. Designed with cadmium-free contact material and ia suitable for general-duty applications. Includes standard socket-mount or solder terminals and nameplate.
Technical Specifications
- Item - Relay General Purpose Relay
- Coil Volts 24V AC
- AC Contact Rating - Relay 10A @ 240V
- DC Contact Rating - Relay 10A @ 28V
- Base Type - Plug In Relay Square
- Number of Pins - Relay 5
- Contact Form - Relay SPDT
- Mounting - Relay Plug In
- Socket Code - Relay H
- Power Consumption - Relay 0.9 VA
- Contact Material Cadmium Free
- Status Indicator Mechanical Flag
- Push To Test Manual
- Body Height - Relay 1.4 in
- Body Width - Relay 0.51 in
- Body Depth - Relay 1.14 in
- Overall Height - Relay 1.6 in
- HP @ 120V 1/3 hp
- HP @ 240V 1/2 hp
- Standards CSA Certified, UL Listed
Manufacturer Details
- Manufacturer: Omron
- Condensed Mfg Number: G2R1SAC24S
- MPN: G2R-1-S-AC24(S)
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MY
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536490080
- GDS Category Name: Plug-In Relays
- GDS Family Name: Relays
- GDS Segment Name: Electrical
- UNSPSC: 39121514
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Switches and controls and relays and accessories
- UNSPSC Commodity ID: 14
- UNSPSC Commodity Name: Power relays
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
