DC Power Supply 12VDC 1.2A 50/60Hz MPN:S8VK-G01512
Omron's DC Power Supply 12VDC 1.2A 50/60Hz is a versatile power supply designed to meet your electronic needs in the lab or in the field. With its wide input voltage range of 100 to 240V AC and output voltage of 12V DC, this power supply can provide stable power for various devices ranging from low-power devices such as test equipment, sensors, and communication modules to high-power applications such as industrial controls and motor drives. The unit has a power rating of 15W and offers an output amperage of 1.2A, making it capable of charging batteries, running small electronic devices, and providing power to sensitive equipment without any voltage fluctuations. Its compact size, lightweight design, and robust build make it portable and durable for on-the-go use, while its mounting features allow easy installation in permanent setups. Overall, Omron's DC Power Supply 12VDC 1.2A is an ideal solution for your electronic power needs and offers unmatched performance, reliability, and efficiency at a competitive price.
Top product features:
- Wide Input Voltage Range (100 to 240V AC)
- Compact and Portable Design
- Robust Build for Durability
Top product applications:
- Charging batteries for electronics on the go
- Powering low-power electronic devices in remote locations
- Providing stable power for sensitive test and measurement equipment
Technical Specifications
- Item DC Power Supply
- Input Voltage 100 to 240V AC
- Output Voltage 12V DC
- Power Rating 15W
- Output Amps 1.2
- Mounting DIN Rail
- Style Switching
- Case Material Plastic Case
- Height 90 mm
- Width 22 mm
- Depth 90 mm
- Series S8VK
- Hz 50/60
- Phase - Electrical 1
- Peak Amps 1.44
- Output Noise 50mV
- Hold Up Time 29 msec
- Status Indicator Green LED
- Features It Also Saves Time And Reduces Costs Thanks To The Minimal Wiring Requirements And Easy One-Handed Mounting Provided By The Enhanced Din-Rail Mounting Clip, More Compact And Easier To Use, The S8VK Series Not Only Offers Greater Flexibility When Designing Machines
- Operating Temp. Range -40 Degrees to 158 Degrees F
- Standards UL Listed: UL 508 (Listing, Class2 Output: Per UL 1310), UL UR: UL 60950-1 (Recognition), cUL : CSA C22.2 No.107.1 (Class2 Output: Per CSA C22.2 No.223), cUR: CSA C22.2 No.60950-1, EN/VDE: EN50178, EN60950-1, Lloyd's standards *7, ANSI/ISA 12.12.01, CSA C22.2 No.213
