H8070 Gen Purpose Relay 5 Pin Square 240VAC MPN:G2R-1-S-AC240(S)
H8070 Gen Purpose Relay 5 Pin Square 240VAC
H8070 is an HACOM Automotive Relay, a reliable 12 volt DC relay that is widely used in various automotive applications. It operates on a low current trigger circuit and has 4 sets of normally open/closed contacts rated at 16 amperes resistive loads and 30 amperes inductive loads. The housing dimensions are 11mm in diameter with a size of 5 square. This general purpose relay comes in a pack quantity of 10 pieces, making it an excellent choice for stocking up on spare parts or replacing defective relays in your vehicle's electrical system.
Get Omron item #G2R-1-S-AC240(S) from our selection of Specialty Electrical Switches & Relays while supporting Veterans 🎖.
Technical Specifications
- Item - Relay General Purpose Relay
- Coil Volts 240V AC
- AC Contact Rating - Relay 10A @ 240V
- DC Contact Rating - Relay 10A @ 28V
- Base Type - Plug In Relay Square
- Number of Pins - Relay 5
- Contact Form - Relay SPDT
- Mounting - Relay Plug In
- Socket Code - Relay H
- Power Consumption - Relay 0.9 VA
- Contact Material Silver Alloy
- Status Indicator Mechanical Flag
- Push To Test Manual
- Body Height - Relay 1.4 in
- Body Width - Relay 0.51 in
- Body Depth - Relay 1.14 in
- Overall Height - Relay 1.6 in
- HP @ 120V 1/3 hp
- HP @ 240V 1/2 hp
- Standards CSA Certified, UL Listed
Manufacturer Details
- Manufacturer: Omron
- Condensed Mfg Number: G2R1SAC240S
- MPN: G2R-1-S-AC240(S)
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MY
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536490080
- GDS Category Name: Plug-In Relays
- GDS Family Name: Relays
- GDS Segment Name: Electrical
- UNSPSC: 39121542
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Switches and controls and relays and accessories
- UNSPSC Commodity ID: 42
- UNSPSC Commodity Name: Solid state relays
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on August 19, 2024 8:20pm UTC
