4 Bolt Flange Brg Radial 1 7/16in Bore MPN:SUCF207-23CC
4 Bolt Flange Brg Radial 1 7/16in Bore
The 4 bolt flange is an essential product for various industrial applications requiring secure connection and durability. Its alloy steel construction ensures high strength and resistance to wear and tear, making it ideal for demanding conditions. With a radial flange style and a bore size of 1-7/16 inches, it accommodates pipes or tubes of specific diameter for easy installation. Furthermore, its four bolt design provides secure connection while allowing adjustments during installation. Common industries using this product include construction, oil & gas, power generation, and engineering, making it an indispensable solution in various fluid transfer applications.
✓ Buy NTN item #SUCF207-23CC and get Free Shipping from our large selection of Hardware Accessories and show your support for Veteran-Owned Businesses.
Technical Specifications
- Item 4-Bolt Flange Bearing
- Mounted Bearing Item 4-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 1-7/16 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Stainless Steel
- Bearing Insert Material 440C Stainless Steel
- Bolt Hole Center-to-Center 92 mm
- Series SUCF
- Bolt Size M12
- Overall Height 48.2mm
- Overall Width 116mm
- Overall Length 116mm
- Bearing Lubrication Caltex FM EP or Equivalent USDA-H1 Grease
- Dynamic Load Capacity 4,520 lb
- Static Load Capacity 3,510 lb
- Temp. Range -4 Degrees to 230 Degrees F
- Finish Chrome
- Includes Stainless Steel End Cap
Manufacturer Details
- Manufacturer: NTN
- Condensed Mfg Number: SUCF20723CC
- MPN: SUCF207-23CC
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: ZZ
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483204040
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Flanged bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on June 10, 2023 12:44am UTC
