Pillow Block Bearing 1 3/4 in Bore SS MPN:SUCP209-28
The 7/8 high by 1-11/16 long Terminal Block C Tap is an essential tool designed for professionals working in electrical or mechanical engineering sectors where secure connections are crucial. Its slotted hole design enables easy tightening of screws onto the terminal blocks, ensuring a strong and reliable connection while reducing chances of accidental loosening. Made from high-grade materials that offer durability and resistance to wear, the tap delivers superior performance over time, allowing for long-lasting usage in demanding environments. Its compact size and lightweight construction enhance portability, making it perfect for use on field assignments or repair works. Further, its versatile design allows users across different industries like manufacturing or maintenance to create secure connections efficiently without the need for recalibrations or adjustments, saving time, money, and resources in the process.
Technical Specifications
- Item Pillow Block Bearing
- Mounted Bearing Item Pillow Block Bearing
- Bearing Insert Type Ball
- Bore Dia. 1 3/4 in
- Bolt Hole Center-to-Center 146 mm
- Mounting Surface to Shaft Center 54 mm
- Bearing Housing Material Type Stainless Steel
- Shaft Locking Type Set Screw
- Bearing Insert Material 440C Stainless Steel
- Series Corrosion Resistant with USDA-H1 Grease
- Number of Bolts 2
- Bolt Size M14
- Overall Height 109 mm
- Overall Width 54 mm
- Overall Length 190 mm
- Bearing Lubrication Caltex FM EP or Equivalent USDA-H1 Grease
- Dynamic Load Capacity 5,780 lb
- Static Load Capacity 4,670 lb
- Temp. Range -4 Degrees to 248 Degrees F
- Finish Chrome
Manufacturer Details
- Manufacturer: NTN
- Condensed Mfg Number: SUCP20928
- MPN: SUCP209-28
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483204040
- GDS Category Name: Pillow Block Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171511
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 11
- UNSPSC Commodity Name: Pillow block bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
