4 Bolt Flng Brg Radial 2 7/16in Bore MPN:SUCF212-39
The 4 Bolt Flange is a durable and reliable radial flange fitting, designed to provide secure connections between pipes and fittings in various industries such as chemical, petrochemical, food processing or power generation plants. With a bore diameter of 2-7/16 inches, it has a strong and corrosion-resistant construction made from stainless steel for durability. Its compact design makes it easy to install and compatible with standard piping systems, while the four bolting holes ensure secure fastening and reliable pressure containment up to 5000psi. This flange is suitable for use with a wide range of media, including water, steam, air, gases or chemicals making it ideal for various applications where safe and leak-free operation is paramount. Its long service life combined with easy maintenance makes this flange an economical choice when reliability and durability are essential requirements in demanding environments.
Technical Specifications
- Item 4-Bolt Flange Bearing
- Mounted Bearing Item 4-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 2 7/16 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Stainless Steel
- Bearing Insert Material 440C Stainless Steel
- Bolt Hole Center-to-Center 143 mm
- Series Corrosion Resistant with USDA-H1 Grease
- Bolt Size M16
- Overall Height 68.7 mm
- Overall Width 175 mm
- Overall Length 175 mm
- Bearing Lubrication Caltex FM EP or Equivalent USDA-H1 Grease
- Dynamic Load Capacity 9,220 lb
- Static Load Capacity 7,080 lb
- Temp. Range -4 Degrees to 248 Degrees F
- Finish Chrome
- Dimension A 175 mm
- Dimension E 143 mm
- Dimension G 18 mm
- Dimension L 48 mm
- Dimension N 25.4 mm
- Dimension S 19 mm
Manufacturer Details
- Manufacturer: NTN
- Condensed Mfg Number: SUCF21239
- MPN: SUCF212-39
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483204040
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Flanged bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
