4 Bolt Flng Brg Radial 2 3/16in Bore MPN:SUCF211-35
Our 4 Bolt Flange Mounted Ball Bearing is designed to accommodate industries that demand high load capacities and sturdy support solutions for their machines or equipment. Suitable for applications like motors or pumps utilizing flanges, this bearing guarantees uninterrupted performance with its enclosed construction. Heavy-duty industries such as machinery or paper mills will benefit significantly from the substantial axial loads and dynamic load ratings that can exceed 700 pounds for radial and 426 pounds for thrust loads. This reliable mounting solution ensures a long service life, making it perfect for applications requiring robust support in demanding conditions. Overall, its versatile application, durability and high-capacity make the 4 Bolt Flange Mounted Ball Bearing an essential component for any industrial setting that requires stable and reliable mounting options.
Technical Specifications
- Item 4-Bolt Flange Bearing
- Mounted Bearing Item 4-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 2 3/16 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Stainless Steel
- Bearing Insert Material 440C Stainless Steel
- Bolt Hole Center-to-Center 130 mm
- Series Corrosion Resistant with USDA-H1 Grease
- Bolt Size M16
- Overall Height 58.4 mm
- Overall Width 162 mm
- Overall Length 162 mm
- Bearing Lubrication Caltex FM EP or Equivalent USDA-H1 Grease
- Dynamic Load Capacity 7,640 lb
- Static Load Capacity 5,730 lb
- Temp. Range -4 Degrees to 248 Degrees F
- Finish Chrome
- Dimension A 162 mm
- Dimension E 130 mm
- Dimension G 18 mm
- Dimension L 43 mm
- Dimension N 22.2 mm
- Dimension S 19 mm
Manufacturer Details
- Manufacturer: NTN
- Condensed Mfg Number: SUCF21135
- MPN: SUCF211-35
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483204040
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Flanged bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
