4 Bolt Flng Brg Radial Ball 1 3/4in Bore MPN:UCFU-1.3/4M
The Solid Carbide Square End Mill is ideal for general-purpose milling operations such as roughing and profiling with ease due to its four flutes which prevent overheating during operation, allowing increased speed when cutting in both soft steel and harder metals. The Square end design allows precise milling of slots, grooves or flat surfaces. With a diameter of 0.036 inches, it can be used in applications with tighter tolerances while its 0.108-inch length of cut (LOC) ensures quick material removal on large surfaces areas. It is suitable for machinists who work in various industries such as automotive, aerospace or medical components manufacturing where tight precision and high-quality finishes are critical. This solid carbide construction guarantees long tool life compared to high-speed steel or other materials making it economically efficient while delivering top-notch results.
Technical Specifications
- Item 4-Bolt Flange Bearing
- Mounted Bearing Item 4-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 1 3/4 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Cast Iron
- Bearing Insert Material 52100 Chrome Steel
- Bolt Hole Center-to-Center 4 1/8 in
- Series Standard Duty
- Bolt Size 7/16 in
- Overall Height 2 9/64 in
- Overall Width 5 13/32 in
- Overall Length 5 13/32 in
- Bearing Lubrication Shell Alvania #3 or NLGI #3 Equivalent
- Dynamic Load Capacity 7,350 lb
- Static Load Capacity 4,600 lb
- Temp. Range -20 Degrees to 250 Degrees F
- Finish Painted
- Dimension A 1 9/16 in
- Dimension Ao 2 9/64 in
- Dimension B 1 15/16 in
- Dimension D 1 3/4 in
- Dimension J 4 1/8 in
- Dimension L 5 13/32 in
- Dimension N 33/64 in
- Dimension S 3/4 in
Manufacturer Details
- Manufacturer: NTN
- Condensed Mfg Number: UCFU134M
- MPN: UCFU-1.3/4M
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: JP
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483204040
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Flanged bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
