4 Bolt Flng Brg Radial Ball 1 1/8in Bore MPN:UCFU-1.1/8M
This versatile and highly durable sling made from dyneema with nylon webbing delivers incredible strength for a variety of applications across numerous industries without damaging your load or surfaces while providing consistent performance with minimal stretch, abrasion and fade resistance to prolong its lifespan even under extreme temperatures or conditions. With a 1.75-inch width, this slings enables quick identification for safer handling while preventing overload with clear marking of working load limits, suitable for use in construction, forestry, rigging or material handling tasks and rated at 14 feet long with maximum capacity of 30,000 pounds as a basket and vertical and choker up to 12,000 pounds, ensuring reliable grip onto materials for hassle-free use anytime you need it. Its affordable price point offers unbeatable value while preventing downtime from theft or accidental damage by offering enhanced security and the peace of mind that your loads are always safe at every jobsite where safety is of paramount importance.
Technical Specifications
- Item 4-Bolt Flange Bearing
- Mounted Bearing Item 4-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 1 1/8 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Cast Iron
- Bearing Insert Material 52100 Chrome Steel
- Bolt Hole Center-to-Center 3 1/4 in
- Series Standard Duty
- Bolt Size 3/8 in
- Overall Height 1 21/32 in
- Overall Width 4 9/32 in
- Overall Length 4 9/32 in
- Bearing Lubrication Shell Alvania #3 or NLGI #3 Equivalent
- Dynamic Load Capacity 4,400 lb
- Static Load Capacity 2,540 lb
- Temp. Range -20 Degrees to 250 Degrees F
- Finish Painted
- Dimension A 1 5/16 in
- Dimension Ao 1 21/32 in
- Dimension B 1 1/2 in
- Dimension D 1 1/8 in
- Dimension J 3 1/4 in
- Dimension L 4 9/32 in
- Dimension N 29/64 in
- Dimension S 5/8 in
Manufacturer Details
- Manufacturer: NTN
- Condensed Mfg Number: UCFU118M
- MPN: UCFU-1.1/8M
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: JP
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483204040
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Flanged bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
