2 Bolt Flng Brg Radial 1 7/16in Bore MPN:UCFLU-1.7/16M
The Ball Grip Quick-Release Pin features a spring-loaded, snap-in mechanism for easy installation and removal with one hand using the included button handle. Made from heat-treated high carbon steel for maximum strength, this pin is designed to withstand repetitive cycles of tightening and loosening without any deformation or breaking. With a pin diameter of 10mm and usable length of 40mm, it's perfect for applications where secure and temporary fastening is required such as attaching covers, fixtures, or guards on machinery, equipment or vehicles, as well as in construction and industrial settings where repeated use is necessary. By providing a simple yet reliable solution to hold materials together without needing extra tools, the Ball Grip Quick-Release Pin streamlines maintenance, repairs or assemblies while ensuring safety by reducing risk of injury due to accidental pin movements.
Technical Specifications
- Item 2-Bolt Flange Bearing
- Mounted Bearing Item 2-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 1 7/16 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Cast Iron
- Bearing Insert Material 52100 Chrome Steel
- Bolt Hole Center-to-Center 5 1/8 in
- Series Standard Duty
- Bolt Size 7/16 in
- Overall Height 1 53/64 in
- Overall Width 3 25/32 in
- Overall Length 6 5/32 in
- Bearing Lubrication Shell Alvania #3 or NLGI #3 Equivalent
- Dynamic Load Capacity 5,750 lb
- Static Load Capacity 3,450 lb
- Temp. Range -20 Degrees to 250 Degrees F
- Finish Painted
- Dimension A 1 13/32 in
- Dimension Ao 1 53/64 in
- Dimension B 1 11/16 in
- Dimension D 1 1/16 in
- Dimension H 6 5/32 in
- Dimension J 5 1/8 in
- Dimension L 3 25/32 in
- Dimension N 33/64 in
- Dimension S 11/16 in
Manufacturer Details
- Manufacturer: NTN
- Condensed Mfg Number: UCFLU1716M
- MPN: UCFLU-1.7/16M
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: JP
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483204040
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Flanged bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
