2 Bolt Flng Brg Radial 1 11/16in Bore MPN:UCFLU-1.11/16M
A reliable solution for a variety of sectors including food and beverage, chemicals, petrochemical or machinery maintenance, the 2-bolt flange radial ball valve offers versatility in size options as well from class 150 to class 600 ensuring optimal performance on each application. This cost-effective alternative provides leak-free and responsive operation essential for fluid control management preventing unauthorized use or leaks with its lockout feature while also providing easy identification of the valve's position allowing for streamlined maintenance, troubleshooting or installation. An ideal choice for professionals looking to enhance their industrial operations with dependable components that reduce downtime or repair expenses in demanding environments where consistent performance is crucial.
Technical Specifications
- Item 2-Bolt Flange Bearing
- Mounted Bearing Item 2-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 1 11/16 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Cast Iron
- Bearing Insert Material 52100 Chrome Steel
- Bolt Hole Center-to-Center 5 27/32 in
- Series Standard Duty
- Bolt Size 7/16 in
- Overall Height 2 9/64 in
- Overall Width 4 3/8 in
- Overall Length 7 3/32 in
- Bearing Lubrication Shell Alvania #3 or NLGI #3 Equivalent
- Dynamic Load Capacity 7,350 lb
- Static Load Capacity 4,600 lb
- Temp. Range -20 Degrees to 250 Degrees F
- Finish Painted
- Dimension A 1 9/16 in
- Dimension Ao 2 9/64 in
- Dimension B 1 15/16 in
- Dimension D 1 11/16 in
- Dimension H 7 3/32 in
- Dimension J 5 27/32 in
- Dimension L 4 3/8 in
- Dimension N 33/64 in
- Dimension S 3/4 in
Manufacturer Details
- Manufacturer: NTN
- Condensed Mfg Number: UCFLU11116M
- MPN: UCFLU-1.11/16M
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: JP
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483204040
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Flanged bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
