Disc Bearing Square 1.531 in Non-Flanged MPN:DC211TTR3E
The disc bearing square is a precision tool crafted from high-quality tool steel alloy to offer exceptional rigidity, accuracy, and durability that guarantees precision measurements are always achieved with ease. This versatile square fits securely into scribe holders for effortless maneuvering while working on materials of all sorts, thanks to its non-flanged design making it lightweight and easy to handle. The gradated scale measuring in inches allows you to mark precise measurements without errors or wobbling every time with consistent performance delivering the same precision each time whether you are a professional engineer, surveyor, mechanic or carpenter. Perfect for DIY enthusiasts and various industries that require accurate measurements where impeccable precision matters most, this bearing square guarantees that precision is always at hand every time in demanding applications.
Technical Specifications
- Item Agricultural Disc Bearing
- Bearing Type Square Bore, Cylindrical Outer Ring
- Bore Dia. 1.5 in
- Bore Tolerance +/-0.005 in
- Outside Dia. 3.937 in
- Outside Dia. Tolerance +0/-0.0006 in
- Flange Size Not Applicable
- Width 1.75 in
- ABEC Tolerance 1
- Dynamic Load Capacity 9,750 lb
- Static Load Capacity 6,550 lb
- Max. RPM 430 RPM
- Temp. Range -13 Degrees to 250 Degrees F
- Bearing Material Steel
- Cage Material Nylon
- Seal Material NBR
- Lubrication Shell Alvania #3
Manufacturer Details
- Manufacturer: NTN
- Condensed Mfg Number: DC211TTR3E
- MPN: DC211TTR3E
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: JP
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8482105052
- GDS Category Name: Agricultural Disc Ball Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171504
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Ball bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
