3 Bolt Flng Brg Radial Ball 1 1/4in Bore MPN:SUCFBL206-20
SKU
226-CXO-49C724
3 Bolt Flng Brg Radial Ball 1 1/4in Bore
Keep your plumbing projects secure with our Compression Tube Male Elbow - designed to hold up even in tight spaces, this versatile fitting is perfect for both DIY enthusiasts and professionals who need a dependable option they can trust. Protect your peace of mind knowing that your installations are reliable and trustworthy.
✓ Buy NTN item #SUCFBL206-20 and get Free Shipping from our large selection of Hardware Accessories and show your support for Veteran-Owned Businesses.
Technical Specifications
- Item 3-Bolt Flange Bearing
- Mounted Bearing Item 3-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 1 1/4 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type PBT
- Bearing Insert Material 52100 Chrome Steel
- Bolt Hole Center-to-Center 1 7/8 in
- Series Corrosion Resistant
- Bolt Size M10
- Overall Height 76 mm
- Overall Width 41.5 mm
- Overall Length 138.5 mm
- Bearing Lubrication Caltex FM EP or Equivalent USDA-H1 Grease
- Dynamic Load Capacity 3,750 lb
- Static Load Capacity 2,030 lb
- Temp. Range -4 Degrees to 230 Degrees F
- Finish None
- Dimension A 5 29/64 in
- Dimension B 1 1/2 in
- Dimension E 1 7/8 in
- Dimension F 3 in
- Dimension G 33/64 in
- Dimension H 2 1/16 in
- Dimension J 1 1/4 in
- Dimension L 3 1/4 in
- Dimension S 27/64 in
Manufacturer Details
- Manufacturer: NTN
- Condensed Mfg Number: SUCFBL20620
- MPN: SUCFBL206-20
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: ZZ
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483204040
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Flanged bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 3, 2024 10:10pm UTC
Category: Bearings
