Radial Ball Brg 6203 17mm Bore Alloy Stl MPN:6203HT200ZZ

For use in high-heat applications, this high-temperature radial ball bearing offers stability at various temperatures, and is designed to adapt to operating conditions. With rust-resistant steel shields, it also helps maintain stability in the presence of water. Greases are selected to help enhance operating performance, reducing the possibility of lubricant breakdown. Cages are constructed of pressed steel for high tolerance. Use wherever you need bearings that can withstand high temperatures.

Technical Specifications

• Item Radial Ball Bearing
• Unmounted Bearing Item Radial Ball Bearing
• Single Row/Double Row Single Row
• Seal/Shield Type Double Shielded
• Bore Dia. 17 mm
• Bore Tolerance +0/-8 micron
• Outside Dia. 40 mm
• Outside Dia. Tolerance +0/-11 micron
• Width 12 mm
• Seal Material Viton
• Shield Material Steel
• ABEC Tolerance 1
• Dynamic Load Capacity 2,150 lb
• Static Load Capacity 1,100 lb
• Max. RPM 5,200 RPM
• Temp. Range 300 Degrees to 400 Degrees F
• Bearing Material Steel
• Cage Material Steel
• Lubrication Hi Temp
• Industry Number 6203HT200ZZ

Manufacturer Details

• Manufacturer: NTN
• Condensed Mfg Number: 6203HT200ZZ
• MPN: 6203HT200ZZ

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: TR
• CA Prop 65 Wht Label: N

Classification Details

• Harmonization Code: 8482105048
• GDS Category Name: Radial and Deep Groove Ball Bearings
• GDS Family Name: Bearings
• GDS Segment Name: Power Transmission
• UNSPSC: 31171504
• UNSPSC Class ID: 15
• UNSPSC Commodity Name: Bearings
• UNSPSC Commodity ID: 04
• UNSPSC Commodity Name: Ball bearings
• UNSPSC Family ID: 17
• UNSPSC Family Name: Bearings and bushings and wheels and gears
• UNSPSC Segment ID: 31
• UNSPSC Segment Name: Manufacturing Components and Supplies

Shipping Details

• Not For Sale In: HI AK PR
