Radial Ball Brg 6203 17mm Bore Alloy Stl MPN:6203FT150
Keep your machinery operating at peak performance with this high-temperature radial ball bearing from NTN. Ideal for use in high heat applications, this bearing provides stability and durability under various temperatures. The rust-resistant steel shields protect against corrosion caused by moisture or water, while the grease helps enhance performance in challenging operating conditions. Made with pressed steel cages for high tolerances, this bearing is suitable for use wherever you need bearings that can withstand heat and maintain stability. Its double-sealed design also ensures that lubricant breakdown is minimized, increasing the efficiency of your machinery. Get your NTN High-Temperature Radial Ball Bearing today and experience the benefits of reliable operation in even the harshest environments!
Top product features:
- High-temperature stability and durability
- Rust-resistant steel shields for water protection
- Double-sealed design to minimize lubricant breakdown
Top product applications:
- Automotive engineering for high-heat operating conditions
- Machinery manufacturing where moisture may be present
- Equipment repair or maintenance in challenging environments
Technical Specifications
- Item Radial Ball Bearing
- Unmounted Bearing Item Radial Ball Bearing
- Single Row/Double Row Single Row
- Seal/Shield Type Double Sealed
- Bore Dia. 17 mm
- Bore Tolerance +0/-8 micron
- Outside Dia. 47 mm
- Outside Dia. Tolerance +0/-11 micron
- Width 14 mm
- Seal Material Viton
- Shield Material Steel
- ABEC Tolerance 1
- Dynamic Load Capacity 2,100 lb
- Static Load Capacity 1,100 lb
- Max. RPM 11,000 RPM
- Temp. Range 230 Degrees to 250 Degrees F
- Bearing Material Steel
- Cage Material Steel
- Lubrication Hi Temp
- Industry Number 6203FT150
Manufacturer Details
- Manufacturer: NTN
- Condensed Mfg Number: 6203FT150
- MPN: 6203FT150
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: TR
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8482105048
- GDS Category Name: Radial and Deep Groove Ball Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171504
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Ball bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
