Butterfly Valve Lug 2 1/2 In EPDM Liner MPN:CL223E 2 1/2
SKU
226-CXO-1JBD3
Butterfly Valve Lug 2 1/2 In EPDM Liner
Produce crisp white labels quickly with this high-quality label maker label designed for long lasting durability in many different environments. Made from sturdy polypropylene material, the label is sized at a length of 53/64 inches and width of 1/4 inches to fit various labeling needs easily. Capable of producing an impressive amount of 1,500 labels per roll for versatile use, it comes in packs of one roll. Perfect for offices or businesses needing to organize information on boxes, binders, and files quickly and accurately, you'll save time and effort with this user-friendly product. Don't delay; purchase your label maker labels today!
Cast- and Ductile-Iron Butterfly Valves • Max. pressure: 200 psi EPDM liner temp. range: -30° to 250°F Buna liner temp. range: 10° to 180°F Viton® liner temp. range: -20° to 300°FDesigned for commercial mechanical and industrial processes, including hot and cold domestic water, HVAC, condenser and chilled water, and compressed air and vacuum services.Meet MSS-SP67, MSS-SP25, and API-609.Cast-IronHeavy-duty, low-torque valves are dead-end service rated at 150 psi; 200 psi for Buna and EPDM lug style.
Technical Specifications
- Item Butterfly Valve
- Style Lug
- Body Material Cast Iron
- Max. Water Pressure 200 psi
- Pipe Size 2 1/2 in
- Temp. Range -30 to 250 Degrees F
- Liner Material EPDM
- Disc Material Aluminum/Bronze
- Handle Type Lever
- Number of Bolt Holes 4
- Bolt Circle Dia. 5 1/2 in
- Lug Dia. 5/8-11
- Standards MSS-SP25 And API-609, MSS-SP67
Manufacturer Details
- Manufacturer: Milwaukee
- Condensed Mfg Number: CL223E212
- MPN: CL223E 2 1/2
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8481809035
- GDS Category Name: Butterfly Valves
- GDS Family Name: Flow Control Valves
- GDS Segment Name: Plumbing
- UNSPSC: 40141619
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Valves
- UNSPSC Commodity ID: 19
- UNSPSC Commodity Name: Butterfly lug pattern valves
- UNSPSC Family ID: 14
- UNSPSC Family Name: Fluid and gas distribution
- UNSPSC Segment ID: 40
- UNSPSC Segment Name: Distribution and Conditioning Systems and Equipment and Components
Shipping Details
- Not For Sale In: HI AK PR
Related ASINs: B07SSJ1C8H
Product info last updated on October 26, 2023 11:55pm UTC Category: Flow Control Valves
