Steam Trap 1-1/4 NPT Outlet SS Disc MPN:IB15-5-30
Ensure smooth operation within your steam system using our steam trap; engineered with high precision and built to last. This robust construction, designed specifically for size 1-1/4 NPT outlets, employs the Bernoulli Principle to detect condensate build up effectively - minimizing pressure drops, energy losses and system downtime caused by trapped steam pockets. Manufactured from premium stainless steel materials ensures corrosion resistance even under high-pressure conditions typical within industries such as food processing or pharmaceutical factories; safeguarding your equipment for optimal efficiency! In addition, this versatile component is widely used across numerous industrial applications requiring controlled steam flow; including textile machinery and heating systems proving its adaptability no matter the task.
Technical Specifications
- Item Steam Trap
- (F)NPT Connections 1 1/4 in
- Max. Operating PSI 30 psi
- End to End Length 10 1/4 in
- Condensate Capacity Lbs/Hr 9,825
- Max. Temp. 450 Degrees F
- Type Inverted Bucket
- Downstream PSI Range 0 to 25 psi
- Body Material Cast Iron
- NPT Inlet 1 1/4 in
- NPT Outlet 1 1/4 in
- NPT Port 1 1/4 in
- Disc Material Stainless Steel
- Pipe Configuration Straight
- Trap Position Horizontal
- Pressure Air Vent Releases Air and Non-Condensable Gases That Adversely Affect The Heat Transfer of A Steam System
- Application Steam
Manufacturer Details
- Manufacturer: Mepco
- Condensed Mfg Number: IB15530
- MPN: IB15-5-30
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Steam Traps
- GDS Family Name: HVAC Controls and Thermostats
- GDS Segment Name: HVAC and Refrigeration
- UNSPSC: 40142503
- UNSPSC Class ID: 25
- UNSPSC Commodity Name: Traps and strainers
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Steam traps
- UNSPSC Family ID: 14
- UNSPSC Family Name: Fluid and gas distribution
- UNSPSC Segment ID: 40
- UNSPSC Segment Name: Distribution and Conditioning Systems and Equipment and Components
Shipping Details
- Not For Sale In: HI AK PR
