H7834 Time Delay Relay 120VAC/DC 10A DPDT MPN:TR-50222-14
H7834 Time Delay Relay 120VAC/DC 10A DPDT
Introducing Macromatics Time Delay Relay, an essential device for any application requiring delayed switching between power sources. This versatile relay boasts a timing range of 9-900 seconds, making it suitable for use in a wide array of settings where precise timing is crucial. With its 120V AC/DC input voltage and 10A DPDT output contacts, this durable relay can handle even the most demanding applications with ease. Utilizing an 8 pin octal socket for easy installation, the Macromatic Time Delay Relay provides reliable performance and long-lasting dependability. Whether used in industrial, commercial, or residential settings, this powerful yet affordable timing relay is sure to become a valued asset to any toolkit or workshop.
Top product features:
- Adjustable timing range of 9-900 seconds
- 10A DPDT output contacts
- Utilizing an 8 pin octal socket
Top product applications:
- Controlling lights in a warehouse allowing time for employees to safely leave before shutting off lights to save energy costs.
- Timing circuit breakers in large electrical equipment to prevent overloading or damaging the components.
- Delay starting of an industrial fan in case it comes into contact with human bodies, reducing risk of injuries from rapid starting
Macromatic’s Time Delay Relay features an On Delay function with an adjustable timing range of 9-900 seconds, 120V AC/DC input voltage and 10A DPDT output contacts, utilizing an 8 pin octal socket.
Technical Specifications
- Item - Relay Single Function Timing Relay
- Function - Timing Relay On Delay
- Coil Volts 120V AC/DC
- AC Contact Rating - Relay 10A @ 240V
- DC Contact Rating - Relay 10A @ 30V
- Base Type - Plug In Relay Octal
- Number of Pins - Relay 8
- Mounting - Relay Plug In
- Contact Form - Relay DPDT
- Power Consumption - Relay 2.0 W, 2.5 VA
- Adjustment Method - Timer Potentiometer
- Min. Time Setting - Timer 9.0 sec
- Max. Time Setting - Timer 15 min
- Status Indicator None
- Contact Material Silver Nickel
- Body Height - Relay 2.9 in
- Body Width - Relay 2.4 in
- Body Depth - Relay 1.7 in
- Overall Height - Relay 3.1 in
- Electrical Connection Socket
- Socket 1EGP3, 1EGP5, 5X852
- Hz - Electrical 50 Hz, 60 Hz
- Standards CE, CSA, UR
Manufacturer Details
- Manufacturer: Macromatic
- Condensed Mfg Number: TR5022214
- MPN: TR-50222-14
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536490075
- GDS Category Name: Time-Delay Relays
- GDS Family Name: Relays
- GDS Segment Name: Electrical
- UNSPSC: 39121519
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Switches and controls and relays and accessories
- UNSPSC Commodity ID: 19
- UNSPSC Commodity Name: Time relays
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
