Fuse Midget 3-2/10A FLM Series MPN:FLM03.2
SKU
226-CXO-486J08
Fuse Midget 3-2/10A FLM Series
The Fuse Midget 3-2/10A FLM Series is a miniature fast-acting fuse with high interrupt capacity, designed for protecting electrical circuits from overload and short-circuit currents. Its compact size and low profile make it ideal for use in tight spaces, while its 3-2/10A rating allows it to handle up to 2.5KW of power. The FLM Series has a ceramic body and brass cap, providing high mechanical strength and electrical stability. It is commonly used in appliances, electronics, telecommunication equipment, and automotive applications, ensuring reliable circuit protection against potential hazards.
Time-delay, nonindicating midget fuses tolerate temporary inrush currents without opening, which prevents nuisance-blowing from motor and equipment startups. Also called slow-blow midget fuses, they open to disconnect an electrical circuit when exposed to sustained loads and short circuits. They have no indicator for identifying a blown fuse, so they're sometimes used with an indicating fuse block or cover.Midget fuses supplement the primary branch-circuit fuse or breaker to provide backup overcurrent protection for lighting, solenoid, motor, and transformer circuits. Also known as 5AG fuses, they have lower interrupting ratings than branch-circuit protectors. They are noncurrent-limiting, so they won't limit exposure to the full magnitude and duration of an overcurrent.
Technical Specifications
- Item Fuse
- Amps 3 2/10 A
- AC Voltage Rating 250V AC
- DC Voltage Rating Not Rated
- Class Midget
- Series FLM
- Visual Indication Nonindicating
- Speed Time Delay
- Body Style Cylindrical
- Fits Fuse Block Style Nonrejection
- Interrupt Rating 10kA at 250V AC
- Fuse Size 1-1/2 in L x 13/32 in dia
- Length 1 1/2 in
- Diameter 13/32 in
- Equivalent Brand and Series Bussmann FNM, Littelfuse FLM, Mersen TRM
- Equivalent Series FLM, FNM, TRM
- Compatible Fuse Block Series L600M
- Body Material Fiberglass
- Element Single
- Standards CSA Certified, QPL, RoHS, UL Listed
Manufacturer Details
- Manufacturer: Littelfuse
- Condensed Mfg Number: FLM032
- MPN: FLM03.2
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: Y
- CA Prop 65 Cancer Warning: Lead
- CA Prop 65 Repro Warning: Lead
- CA Prop 65 Warning Msg Scenario: 4
Classification Details
- Harmonization Code: 8536100040
- GDS Category Name: Midget Fuses
- GDS Family Name: Fuses
- GDS Segment Name: Electrical
- UNSPSC: 39121609
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 09
- UNSPSC Commodity Name: Midget fuses
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on June 10, 2023 12:39am UTC
Category: Fuses
