Pressure Transmitter 0 to 500 psi 1/8 in MPN:P599AAPS105K
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-CXO-53CW15
Pressure Transmitter 0 to 500 psi 1/8 in
Tekton's Pressure Transmitter 0 to 500 psi 1/8 in offers precise pressure measurement capabilities for various applications such as hydraulic and pneumatic systems, medical devices, and process control industries. Its compact design allows for easy installation in tight spaces while its 0-500psi input range ensures versatility. The transmitter provides accurate and reliable pressure readings, making it an essential tool for professionals seeking high-quality measurement solutions in precision machining or manufacturing environments. With a durable design that withstands harsh conditions, this transmitter is ideal for long-term use and cost-effective for wide range of applications.
This pressure transmitter produces an analog signal based on the sensed pressure. It is ideal for use in air conditioning and commercial refrigeration applications.
Technical Specifications
- Transmitter Type Pressure Transmitter
- Wetted Materials - Transmitters 304L Stainless Steel
- Range Values - Transmitter 0 to 500
- Range Units - Transmitter psi
- Accuracy - Transmitter +/-1.50%
- Electrical Connections - Transmitter Packard Connector with 6-1/2 ft Wiring Harness
- Power Required - Transmitters 9 to 32V DC
- Process Connection Size - Transmitter 1/8 in
- Process Connection Type - Transmitter MNPT
- Output - Transmitter 4 to 20mA DC
- Operating Temp. - Transmitter -40 Degrees to 212 Degrees F
- Wiring Entry - Transmitter None
- Calibration Certificate No
- Housing 304L Stainless Steel
- Loop Resistance Minimum Between Transducer Body and Any Wire: 100 megaohm @ 500V DC
- Max. Pressure (PSI) 500 psi
- For Use With Any Corrosive or Non-Corrosive Pressure Medium That is Compatible with 304L Stainless Steel, Including Water, Condensate, Carbon Dioxide, Glycol, Most Refrigerants Including Ammonia, Many Other Compatible Fluids and Gases
- Compatible With All Media Compatible with 304L Stainless Steel, Including Ammonia
- Includes 6 ft 6 in Wiring Harness
- Manufacturers Warranty Length 3 yr
Manufacturer Details
- Manufacturer: Johnson Controls
- Condensed Mfg Number: P599AAPS105K
- MPN: P599AAPS105K
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026204000
- GDS Category Name: Standard Pressure and Vacuum Transmitters
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112107
- UNSPSC Class ID: 21
- UNSPSC Commodity Name: Transducers
- UNSPSC Commodity ID: 07
- UNSPSC Commodity Name: Electro pneumatic transducers
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on June 10, 2023 12:33am UTC
Category: Pressure and Vacuum Measuring
