Electric Actuator 35 in.-lb.-4 to 125F MPN:M9104-GGA-2S
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-CXO-41P470
Electric Actuator 35 in.-lb.-4 to 125F
The electric actuator is an ideal device for precise and efficient movement of valves, dampers, and other industrial equipment with a range of up to 4 inches of displacement per stroke at its standard operating pressure range from 35 ft.-lb. to 20 psi (0 to 14 bar) providing maximum torque output up to 125 Fc @ 16 ft./second. With an operating temperature ranging from -4F (-20C) to 185F (85C), this electric actuator performs well in extreme temperature environments across multiple industries such as oil and gas, petrochemical, water treatment, and waste management where precise automation is vital.
Designed to position balancing, control, round, and zone dampers in HVAC systems. This non-spring return electric actuator is also designed to position blades in a VAV box, or it can be used in VVT 2-position zone applications. Long life brushless synchronous drive motor technology helps provide constant running time independent of load. The small, compact design allows installation in tight-fitting locations designed for zone damper actuator applications. Simple direct coupling helps reduce installation time and improves reliability by eliminating damper linkages. No additional linkages or couplers are required. A single screw coupling provides 3-pt. shaft gripping.
Technical Specifications
- Item Electric Actuator
- Mounting Type Direct Mount
- Spring Return No
- Shaft Type Self-Centering Clamping
- Torque 35 in-lb
- Stroke Deg. 90
- Height 5 5/32 in
- Width 2 13/16 in
- Depth 2 1/4 in
- Electrical Connections Cable
- Signal Type Proportional
- Motor Direction CW or CCW
- Ambient Temp. Range -4 Degrees to 125 Degrees F
- Power Consumption 3.6VA
- Timing 60 sec
- Voltage 24V AC
- For Use With Dampers and Valves
- Replaces Honeywell Motors Mfr. No. ML7161A2008
- Includes Anti Rotation Bracket
Manufacturer Details
- Manufacturer: Johnson Controls
- Condensed Mfg Number: M9104GGA2S
- MPN: M9104-GGA-2S
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8501104020
- GDS Category Name: Electric Actuators
- GDS Family Name: HVAC Controls and Thermostats
- GDS Segment Name: HVAC and Refrigeration
- UNSPSC: 31251501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Actuators
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Electric actuators
- UNSPSC Family ID: 25
- UNSPSC Family Name: Pneumatic and hydraulic and electric control systems
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Related ASINs: B008FM2WJW, B00DARQRHA, B00DARTOES
Product info last updated on November 3, 2023 11:47pm UTC Category: HVAC Controls and Thermostats
