Pneumatic Tstat Heat or Cool 2Pipe High MPN:T-4506-217

This dual-temperature, dual-dial pneumatic room thermostat provides individual day/night, or 2 set point temperature control in HVAC applications, while placing minimal demand on heating and cooling apparatus, to help save you money on energy costs and wear and tear. Lower and upper set points are independent of one another—a change in one does not affect the other, giving you the flexibility to maximize energy savings and comfort at the same time.

Technical Specifications

• Item Pneumatic Thermostat
• Action Type Reverse Acting
• No. of Pipes 2 Pipe
• Thermostat Application Heating and Cooling
• Temperature Output Settings Dual Temperature
• Control Air Pressure 3 to 15 psi
• Air Connections 5/32 in Barb
• Max. Air Pressure 25 psi
• Max. Ambient Temp. 135 Degrees F
• Mounting Style Horizontal
• Height 2 3/32 in
• Width 3 1/8 in
• Depth 1 3/4 in
• Temp. Control Range 55 Degrees to 85 Degrees F
• Air Consumption 20 scim
• Throttling Range 1 to 5 psi

Manufacturer Details

• Manufacturer: Johnson Controls
• Condensed Mfg Number: T4506217
• MPN: T-4506-217

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: MX
• CA Prop 65 Wht Label: N

Classification Details

• GDS Category Name: Pneumatic Mechanical Thermostats
• GDS Family Name: HVAC Controls and Thermostats
• GDS Segment Name: HVAC and Refrigeration
• UNSPSC: 41112209
• UNSPSC Class ID: 22
• UNSPSC Commodity Name: Temperature and heat measuring instruments
• UNSPSC Commodity ID: 09
• UNSPSC Commodity Name: Thermostats
• UNSPSC Family ID: 11
• UNSPSC Family Name: Measuring and observing and testing instruments
• UNSPSC Segment ID: 41
• UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment

Shipping Details

• Not For Sale In: HI AK PR
