Remote-Control H/C 3 1/8in Length MPN:A19ZBC-2C
Remote control systems provide effortless command and control functionality to complex machinery or equipment from a distance. This 3 1/8 remote control offers the precision and reliability required for applications demanding precise movements such as camera focus adjustments, medical robotics or CNC machining processes among others. With its rugged construction, this remote control unit offers robust operation in challenging environments such as harsh temperatures or tough conditions found on construction sites, ensuring optimal performance time after time. Its ergonomic design delivers ease of use, while its long-lasting battery life helps reduce downtime and increase productivity by allowing users to perform multiple tasks with fewer interruptions. Furthermore, this model's customizable functionalities permit the creation of tailored operating profiles according to each application's specific requirements, enhancing user comfort and efficiency on-the-job.
Technical Specifications
- Item Line Volt Mechanical Tstat
- Thermostat Switch Type SPDT
- Thermostat Control Range 45 Degrees to 85 Degrees F
- Thermostat Voltage 24 to 277V AC
- Full Load Amps @ 120VAC 16 A
- Full Load Amps @ 240VAC 8 A
- Thermostat Programmable No
- Remote Sensing Capability Yes
- Thermostat Heating/Cooling Heating/Cooling
- Thermostat Item Line Voltage Mechanical Thermostat
- Remote Sensing Bulb Included Yes
- Switch Action Open/Close on Rise
- Number of Switches 1
- Differential 4 Degrees F
- Height 4 1/4 in
- Width 3 1/2 in
- Depth 2 in
- Temp. Sensitivity +/-4 Degrees F
- Sensor Type Bulb
- Sensing Bulb Dia. 19/64 in
- Sensing Bulb Length 3 1/8 in
- Capillary Length 72 in
- Color Gray
- Enclosure Type Galvanized/Steel
- Inductive Amps @ 120V 16 A
- Inductive Amps @ 208V 9.2 A
- Inductive Amps @ 240V 8 A
- Locked Rotor Amps @ 120V 96 A
- Locked Rotor Amps @ 240V 48 A
- Contact Rating Resistive @ 120V 22 A
- Resistive Amps @ 208VAC 22 A
- Contact Rating Resistive @ 240V 22 A
- Contact Rating Resistive @ 277V 22 A
- Pilot Duty Contacts (VA) 125 VA
- Mounting Type Flat Surface
- Standards UL SA516, CSA LR948/1222 01
Manufacturer Details
- Manufacturer: Johnson Controls
- Condensed Mfg Number: A19ZBC2C
- MPN: A19ZBC-2C
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Remote-Bulb Sensor Temperature Controls
- GDS Family Name: HVAC Controls and Thermostats
- GDS Segment Name: HVAC and Refrigeration
- UNSPSC: 41112209
- UNSPSC Class ID: 22
- UNSPSC Commodity Name: Temperature and heat measuring instruments
- UNSPSC Commodity ID: 09
- UNSPSC Commodity Name: Thermostats
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
