Electric Actuator 24 to 57 sec.120VAC MPN:M9220-BAA-3
SKU
226-CXG-41P595
Electric Actuator 24 to 57 sec.120VAC
Introducing our state-of-the-art electric actuator, specially designed for smooth operation in HVAC systems. Its spring return system ensures consistent torque without power applied, making it perfect for controlling dampers in a variety of environments. With direct mounting and self-centering clamping technology, the Electric Actuator simplifies installation while delivering reliable performance. Engineered to withstand even the toughest conditions, this powerful actuator offers rated torque up to 177 in-lb, making it ideal for use in commercial and industrial applications alike. Reduce energy consumption and improve overall efficiency with our Electric Actuator the ultimate solution for controlling airflow in your HVAC system.
Top product features:
- Spring return system for consistent torque
- Direct mounting for easy installation
- Self-centering clamping technology for reliable performance
Top product applications:
- HVAC system control for airflow regulation in commercial and industrial settings
- Dampers adjustment for temperature and pressure balancing
- Energy saving by optimizing ventilation systems
Spring-return electric actuator from Johnson Controls provides control of dampers in HVAC systems. It is designed with a mechanical spring-return system that gives rated torque with and without power applied to the actuator. It is also configured for direct mounting and does not require a damper linkage.
Technical Specifications
- Item Electric Actuator
- Mounting Type Direct Mount
- Spring Return Yes
- Shaft Type Self-Centering Clamping
- Torque 177 in-lb
- Stroke Deg. 90
- Height 10 5/16 in
- Width 4 in
- Depth 3 3/16 in
- Electrical Connections Cable
- Signal Type On/Off
- Motor Direction CW or CCW
- Ambient Temp. Range -40 Degrees to 131 Degrees F
- Power Consumption 25VA
- Timing 24 to 57 sec
- Voltage 120V AC
- For Use With Dampers and Valves
- Replaces Honeywell Motors Mfr. No. MS4120A1001
- Includes Anti Rotation Bracket
Manufacturer Details
- Manufacturer: Johnson Controls
- Condensed Mfg Number: M9220BAA3
- MPN: M9220-BAA-3
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8501104060
- GDS Category Name: Electric Actuators
- GDS Family Name: HVAC Controls and Thermostats
- GDS Segment Name: HVAC and Refrigeration
- UNSPSC: 31251501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Actuators
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Electric actuators
- UNSPSC Family ID: 25
- UNSPSC Family Name: Pneumatic and hydraulic and electric control systems
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
