Remote-Control H/C 2 5/8in Length MPN:A19AAD-5C
SKU
226-CXG-38Y050
Remote-Control H/C 2 5/8in Length
This remote-controlled hydraulic cylinder is suitable for use in various industries such as manufacturing, construction, or agriculture, where precise control of equipment, machinery, or vehicles is needed from a safe distance. With its compact design and 2.63 inch stroke length, it is an ideal solution for tight spaces and limited access applications. It allows operators to control hydraulic processes remotely while avoiding hazardous conditions or environments that might compromise their safety.
Get Johnson Controls item #A19AAD-5C from our selection of HVAC Controls while supporting Veterans 🎖.
Technical Specifications
- Item Line Volt Mechanical Tstat
- Thermostat Switch Type SPST
- Thermostat Control Range 30 Degrees to 50 Degrees F
- Thermostat Voltage 24 to 277V AC
- Full Load Amps @ 120VAC 15 A
- Full Load Amps @ 240VAC 3 A
- Thermostat Programmable No
- Remote Sensing Capability Yes
- Thermostat Heating/Cooling Cooling
- Thermostat Item Line Voltage Mechanical Thermostat
- Remote Sensing Bulb Included Yes
- Switch Action Close On Rise
- Number of Switches 1
- Differential 2.5 Degrees F
- Height 4 3/8 in
- Width 2 1/8 in
- Depth 1 13/16 in
- Temp. Sensitivity +/-2 Degrees F
- Sensor Type Bulb
- Sensing Bulb Dia. 3/8 in
- Sensing Bulb Length 2 1/8 in
- Capillary Length 72 in
- Color Gray
- Enclosure Type Galvanized/Steel
- Inductive Amps @ 120V 6 A
- Inductive Amps @ 208V 3.4 A
- Inductive Amps @ 240V 3 A
- Locked Rotor Amps @ 120V 36 A
- Locked Rotor Amps @ 240V 18 A
- Contact Rating Resistive @ 120V 10 A
- Resistive Amps @ 208VAC 10 A
- Contact Rating Resistive @ 240V 10 A
- Contact Rating Resistive @ 277V 10 A
- Pilot Duty Contacts (VA) 125 VA
- Mounting Type Flat Surface
- Standards UL E6688; CSA LR948/4813 02
Manufacturer Details
- Manufacturer: Johnson Controls
- Condensed Mfg Number: A19AAD5C
- MPN: A19AAD-5C
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9032100000
- GDS Category Name: Remote-Bulb Sensor Temperature Controls
- GDS Family Name: HVAC Controls and Thermostats
- GDS Segment Name: HVAC and Refrigeration
- UNSPSC: 41112209
- UNSPSC Class ID: 22
- UNSPSC Commodity Name: Temperature and heat measuring instruments
- UNSPSC Commodity ID: 09
- UNSPSC Commodity Name: Thermostats
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on November 17, 2023 12:18pm UTC
