IEC Combo Str 2.5-4 A 120V Coil 4X Enc MPN:VS-CE0204SSPT
IEC Combo Str 2.5-4 A 120V Coil 4X Enc
The IEC Combo Str 2.5-4 A 120V Coil 4X Enc is a versatile device designed to provide efficient control of lighting fixtures and motor loads in various industries. Its advanced multi-encoder design offers smooth control while providing reliable protection against electrical hazards. Key specifications include a power rating of 2.5 - 4 A and an operating voltage of 120V, making it suitable for demanding applications that require energy savings without compromising on performance.
IEC Combination Motor Starters• Short-circuit and motor overload protection 3-pole, 60/50 Hz 120VAC coil Self-protected, Type E 1NO/1NC auxiliary contact Hand/Off/Auto models have DIN rail-mount terminal blocks for external accessories 100VA transformer (where applicable) NEMA 4XAdjustable motor circuit protector eliminates the need for heater elements (thermal units). Starters have visual short-circuit indicator and LED pilot light.UL Listed, CSA Certified.
Technical Specifications
- Item IEC Combination Starter
- Overload Relay Amp Setting 2.5 to 4A
- Coil Volts 120V AC
- Amps AC 2.5 to 4
- Enclosure NEMA Rating 4X
- Operator Push Button
- Operator Function Start/Stop
- Short Circuit Protection Motor Circuit Protector
- Pilot Light Yes
- Control Transformer Yes
- Control Transformer Voltage 120V AC Secondary, 208, 240, 480V AC Primary
- Auxiliary Contact Form 1NO/1NC
- Hz 50/60
- HP @ 3 Phase - 240V 3/4 hp
- HP @ 3 Phase - 480V 2 hp
- Height 13.31 in
- Width 11.31 in
- Standards UL/CSA
Manufacturer Details
- Manufacturer: Hoffman
- Condensed Mfg Number: VSCE0204SSPT
- MPN: VS-CE0204SSPT
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536504000
- GDS Category Name: IEC Combination Starters
- GDS Family Name: Starters and Contactors
- GDS Segment Name: Electrical
- UNSPSC: 39121521
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Switches and controls and relays and accessories
- UNSPSC Commodity ID: 21
- UNSPSC Commodity Name: Motor starter controls
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 4, 2024 3:43am UTC
Category: Starters and Contactors
