304 Stainless Steel Half Coupling, 3/4 in, Female BSPT x 3/4 in Butt Weld, Class 150 MPN:ZUSA-PF-8074

The ZORO SELECT - ZUSA-PF-8074 is a stainless steel pipe fitting rated for use within low- to medium-pressure systems as specified. It is rated for use within ASME/ANSI Class 150 pressure–temperature limits and is suitable for conveying fluids including water, steam, chemicals, or gases within specified conditions. Constructed from 304 stainless steel, it offers corrosion resistance and durability as specified, suitable for use in piping connections within operational parameters.

Key Features:

• - Application: Rated for use with air, natural gas, oil, potable water, and steam systems within specified conditions
• - Class: Rated for use within ASME/ANSI Class 150 pressure limits
• - Color: Silver
• - Fitting Side A: Female gender with BSPT thread (14 TPI), nominal size 3/4 in
• - Fitting Side A Connection: BSPT
• - Fitting Side B: Butt weld connection, nominal size 3/4 in
• -
• -
• - Material Grade: 304 Stainless Steel
• - Overall Length: 19 mm
• - Rated for operation up to 150 psi under specified conditions
• - Standards: ISO 7-1
• - Low Lead Compliance Level: Compliant
